7.3.1 Special tools
Pos. Description For pos. Further information Part number
A Service tool for loosening and tightening shaft seal 105
For 22 pump shafts 99072586
For 28 and 36 pump shafts 99072587
B Eyebolt with swivel function 51 M10 × 1.5 -
C Key for split-cone nut 48
For 22 pump shafts SV0004
For 28 pump shafts 99072584
For 36 pump shafts 99072585
D T-pin 51 - 99072581
E Service tool for smoothening out marks on shaft 51 - -
F Adjusting fork 105
For 22, 28 and 36 pump
shafts
92582580
G Hook for thrust-handling device 120h - 99176979
H1
Service tool for chamber stack
For vice
99081919
H2 For pump base
I Protection pipe for shaft 51
For 28 pump shafts reduced
to 22 shaft ends
99081891
For 36 pump shafts reduced
to 22 shaft ends
99081920
For 36 pump shafts reduced
to 28 shaft ends
99081890
J
Service tool for alignment of pump head, sleeve and chamber
stack
2, 51
For 22 pump shafts 99072588
For 28 pump shafts 99072589
For 36 pump shafts 99072590
K Punch tools for bush 47, 47c, 47d
For 22 pump shafts 98369955
For 28 and 36 pump shafts 99081918
L Tool for installing neck ring 45a For CR, CRN 95 - 255 99447875
M Protective disc 48
For 28 pump shafts 99381867
For 36 pump shafts 99381868
N Screw-clamp for outer sleeve 55 - 99139064
O Pin for torque wrench 105 14 × 18 × 14 SV0402
P Torque wrench 105 - -
Q Hammering tool 48
For 28 pump shafts 99424834
For 36 pump shafts 99424835
22
English (GB)
