Grundfos CRIE User Manual

English (GB)
26
"Settings"
CRE, CRIE,
CRNE,
SPKE, MTRE
CME
Multipump
system
Section Page
"Setpoint" ●●●13.1 Setpoint 28
"Operating mode" ●●●13.2 Operating mode 28
"Set user-defined speed" ●●●13.4 "Set user-defined speed" 28
"Control mode" ●●●13.5 "Control mode" 28
"Pipe-filling function" ●●●13.19 Pipe filling function 47
"Buttons on product" ●●
13.30 "Buttons on product"
(Enable/disable settings)
50
"LiqTec" ●●
1)
13.17 "LiqTec" (LiqTec
function)
45
"Stop function" ●●●
13.18 "Stop function" (Low-flow
stop function)
45
"Controller" ●●●
13.12 "Controller" (Controller
settings)
40
"Operating range" ●●●13.13 Operating range 41
"Ramps" ●● 13.21 Ramps 48
"Number" ●●
13.25 "Number" (Pump
number)
49
"Radio communication" ●●
13.26 "Radio communication"
(Enable/disable radio comm.)
49
"Analog input 1" ●●
13.6 Analog inputs 33"Analog input 2" ●●
"Analog input 3" ●●
1)
"Pt100/1000 input 1" ●●
1)
13.7 Pt100/1000 inputs 35
"Pt100/1000 input 2" ●●
1)
"Digital input 1" ●●
13.8 Digital inputs 35
"Digital input 2" ●●
1)
"Digital in/output 3" ●●
13.9 Digital inputs/outputs 37
"Digital in/output 4" ●●
1)
"Pulse flowmeter" ●●
13.20 "Pulse flowmeter" (Pulse
flowmeter setup)
48
"Predefined setpoint" ●●●13.15 Predefined setpoints 43
"Analog output" ●●
1)
13.11 Analog output 38
"External setpoint funct." ●●
13.14 External setpoint
function
41
"Signal relay 1" ●●
13.10 "Signal relays" 1 and 2
(Relay outputs)
38
"Signal relay 2" ●●
1)
Only available if an advanced functional module, type FM 300, is fitted.
Continues on page 27.

Grundfos CRIE Specifications

General

Frequency	50/60 Hz
Material	Stainless Steel
Flow Rate	Up to 120 m³/h
Pumped Liquid	Clean, non-aggressive liquids
Voltage	220-240 V / 380-415 V
