DPC is Digital Pump Controller, which is easy to use, programmable device for
single phase pumps (monoblock or submersible). It can be used to control the
pumps up to 15 Ampere.
APPLICATIONS:
DPC is very useful in water and wastewater applications, be it water transfer,
tank filling, tank emptying or even pressure boosting in Hydro-pneumatic
applications. It is an ideal choice in residential, industrial or institutional
segments where water and energy conservation is of utmost importance.
PARAMETER AND SPECIFICATIONS:
Following chart shows main technical parameters & specifications:
LCD screen displays pump running information
Push button calibration
Overload protection
Motor stalled protection
Dry run protection without installing a float
switch Under voltage protection (fixed settings)
Over voltage protection (fixed settings)
Transient surge protection
Memory function when power off & power recovery
Visual & audio alarm for fault prompt
DIP switch settings to make it suitable for different applications like water supply,
drainage or pressure boosting
Auto/Manual switch
Liquid level probes (in case of fully automatic models) for clear water
INTRODUCTION
Main technical characteristics
Control characteristic
Level control (with probes for clear
water or with floats)
Pressure control (with pressure switch)
Rated output current (amperes)
Rated input voltage AC 220V / 50 HZ / Single Phase
Trip response time of overload
Trip response time short circuit
Trip response time of under/over voltage
Trip response time of dry run
Recovery time of overload
Recovery time of under/over voltage
30 min (or this can be set manually)
Trip voltage of over voltage
Trip voltage of under voltage
PROTECTIONS COVERED
Dry run (without float/probe)
Overload (auto calibrated or can be set)
Short circuit
Permissible ambient temperature
Install position Vertical
Unit dimensions (L X W X H)
