Grundfos Hydro Multi-S - 4 Nameplate; 5 Type Key

7
4. Nameplate
The Hydro Multi-S nameplate is placed on the stand.
Fig. 2 Hydro Multi-S nameplate
5. Type key
TM03 9806 4507
Pos. Description
1 Type designation
2 Model
3 Supply voltage
4 Maximum flow rate in m
3
/h
5 Minimum head in metres
6 Weight in kg
7 Number of mains-operated pumps (S-pumps)
8 Motor power in kW
9 Country of origin
Type:
Model:
Main supply:
Q Max:
H Min:
Weight:
S pumps:
Motor size:
Made in
96763706
1
2
3
4
5
6
7
8
9
Example Hydro Multi-S /P 2 CR 3-7 3 x 400 V 50 Hz DOL
Type range
Materials:
: all stainless steel
/G: galvanised-steel base frame and manifolds
/P: galvanised-steel base frame and AISI 304 manifolds
Number of pumps
Pump type
Supply voltage
Frequency
Starting method
DOL: direct on line
