Grundfos IO 100 - Performance Curves

25
Performance curves
SQFlex
TM02 2428 4201
0 50 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900
P1 [W]
0
1
2
3
4
5
6
7
8
9
10
11
[US GPM]
Q
11 SQF-2
300 ft
270 ft
240 ft
210 ft
180 ft
150 ft
120 ft
90 ft
75 ft
60 ft
45 ft
30 ft
15 ft
TM02 2429 4201
0 20 40 60 80 100 120 140 160 180 200 220 240 260 280 300 320 340 360 380 400 420
P1 [W]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
[US GPM]
Q
25 SQF-3
45 ft
30 ft
15 ft
6 ft
