4.4 Identification
Fig. 14 Nameplate, JPA
Fig. 15 Nameplate, JPC
Fig. 16 Nameplate, JPD
TM06 7712 4016TM06 7303 3616
DK-8850 Bjerringbro Denmark
Type: JPA 3-42
No: 98946090 P4 15 47
U: 1x230 V~ I1/1: 3,12 A
50Hz
P1: 0,72 kW
12,5 μF / 450 V~ Class: F
IP: 44
P2: 0,6 HP
Q: 0,4-2,7 m /h H: 38-21 m Hmix: 21 m
Hmax: 42 mn: 2800 min
Made in Hungary by Grundfos
1
17
16
15
14
13
23
4
5
6
18
19
12 11 10 9
3
-1
Serial nr.146783
pmax : 0.8/8 Mpa/bar
Tmax: 35ºC
21
7
8
20
DK-8850 Bjerringbro Denmark
Type: JPC 4-47 No:99074057 P4 1.1628
U: 1x220-240 V~ I1/1:3.8A
50Hz P1:0.85
12.5μF / 450 V~ Class:F
IP:44 P2:0.8HP
Q: 0.4-3.6 m /h H: 41-20 m Tmax:55ºC
n: 2800 min Made in Hungary by Grundfos
1
17
16
15
14
13
23
4
5
6
7
8
12 11 10 9
3
-1
TM06 7713 4016
Pos. Description
1 Pump type
2 Product number
3 Full-load current
4 Factory and production date
5 Motor input power
6 Pump output power
7 Maximum temperature
8 Country of production
9 Frequency
10 Enclosure class
11 Motor insulation class
12 Head
13 Approvals
14 Speed
15 Maximum flow rate
16 Capacitor data
17 Supply voltage
18 Minimum head
19 Maximum head
20 Serial number
21 Maximum pressure
DK-8850 Bjerringbro Denmark
Type: JPD 4-47
No: 98946103 P51. 1549
U: 1x230 V~ I1/1: 4.22 A
50Hz
P1: 0.86 kW
16 μF / 450 V~ Class: F
IP: 44
P2: 0.75 HP
Q: 0.12-2.38 m /h H: 35-15 m Hmix: m
Hmax: mn: 2800 min
Made in China by Grundfos
1
17
16
15
14
13
23
4
5
6
18
19
12 11 10 9
3
-1
pmax : 0.6/6 Mpa/bar
Tmax: 35ºC
21
7
8
Q&H performed
with Ejector E25
& suction depth 9m
PCS 00084.01 04-6292.2.41
LSPr-002-IDN
NPB 119-116-111053
