23
Mechanical Installation
MS Motors
Cooling Sleeve - Horizontally Installed Motor in a
Tank
Fig. 7 Horizontal Installation
Cooling Sleeve - Vertically Insulated Motor in Tank
Fig. 8 Vertical Flow
TM03 0559 0205 - TM03 0560 0205
Water level
Min. 1.5 ft
Baffle Plate
Vortex
W/O Cooling Shroud
Seen from above
Water level
Vortex
Cross section
Baffle Plate
Min. 1.5 ft
W Cooling Shroud
TM03 0561 0205
MS.book Page 23 Wednesday, January 26, 2005 3:25 PM
