Grundfos MS 4000 R User Manual

33
Electrical Data
MS Motors
Motor Protection Chart
1- Phase Motors
3-Phase Motors
HP Ph Volt
Circ. Brkr or Fuses Three Phase Overload Protection
Nameplate
Std. Delay Starter size
Furnas Amb.
Comp
4-Inch, Single Phase, 2-Wire Motors (control box not required)
1/3 1 230 15 5 - - 79952101
1/2 1 115 30 15 - - 79922102
1/2 1 230 15 7 - - 79952102
3/4 1 230 20 9 - - 79952103
1 1 230 25 12 - - 79952104
1 1/2 1 230 35 15 - - 79952105
4-Inch, Single Phase, 3-Wire Motors
1/3 1 115 25 10 - - 79423101
1/3 1 230 15 5 - - 79453101
1/2 1 115 30 15 - - 79423102
1/2 1 230 15 7 - - 79453102
3/4 1 230 20 9 - - 79453103
1 1 230 25 12 - - 79453104
1.5 1 230 30 15 - - 79453105
2 1 230 30 15 - - 79454506
3 1 230 45 20 - - 79454507
5 1 230 70 30 - - 79454509
HP Ph Volt
Circ. Brkr or Fuses Three Phase Overload Protection
Nameplate
Std. Delay Starter size
Furnas Amb.
Comp
4-Inch, Three Phase, 3-Wire Motors
1 1/2 3
230 15 8 0 K41 79302005
460 10 4 0 K32 79362005
575 10 4 0 K28 79392005
23
230 20 10 0 K50 79302006
460 10 5 0 K34 79362006
575 10 4 0 K31 79392006
33
230 30 15 0 K54 79302006
460 15 7 0 K37 79362007
575 15 6 0 K36 79395507
53
230 40 25 1 K61 79304509
460 20 12 0 K50 79354509
575 15 9 0 K43 79394509
7 1/2 3
230 60 30 1 K67 79305511
460 35 15 1 K56 79355511
575 30 15 1 K53 79395511
10 3
460 50 25 1 K61 79355512
575 40 20 1 K58 79395512
MS.book Page 33 Wednesday, January 26, 2005 3:25 PM
