TEChNICAl SPECIFICATIONS
DESCRIPTION MP1 SPE
Part I Rated Power & Markings
Single Phase Input Voltage 115V +/- 10% or 230V +/- 10%
Output Voltage 3 X 230V
Continuous Output Current 8.7A @1x115v (input)
Part II Fundamental Parameters
Control System PWM
Output Voltage Clamp @ 230V
Carrier Freq. Selectable: 1-5 KHz
Freq. Resolution 0.01Hz
Input Freq. Range 48 – 62 Hz
Maximum Output Frequency 400 Hz 100 Hz*
Base Frequency 400 Hz 100 Hz
Torque Boost 0 – 15% Nominal Voltage
V/F Pattern Selectable Linear/Square Law
Accel Time 0 – 3600 Seconds
Decel Time 0 – 3600 seconds
Accel/Decel Pattern Linear
* The SPE can operate up to 100Hz on 115v but in cases of higher pump loads the motor amperage
could exceed the VFD output rating, causing an over amperage fault.
