15
TEChNICAl SPECIFICATIONS
Part III I/O Capabilities
+24VDC +24VDC, 200 mA supply
Common 24VDC common
2 Analog Ouputs 0-5VDC, function programmable
Analog Input
0-5VDC, 0-10VDC, 4-20mADC, Potentiometer,
for speed control
Digital Inputs Start, Stop, Reset
Digital Opto-Outputs 60 mA, 10-30VDC, function programmable
Digital Relay Outputs
5 A, 10-30 VDC or 230 VAC function
programmable
Part IV Protective Functions
Ground Fault Ground Fault detection for Equipment Protection
Overcurrent Output Short Circuit
Locked Rotor
Over Voltage 400VDC
Under Voltage 200VDC
Motor Overload Vt & Ct = 150% for 60sec
Line Start Lock Out VFD will not start upon input power application
Line Transient Rating 860 VAC, 810J MOV Between any power input
terminal & Ground
360 VAC, 380 J MOV Between any two power
input terminals
Part V Ambient Operating Conditions
Operating Temp. -10 to 45 degree C
Storage Temp. -10 to 65 degree C
Humidity 10 to 90% RH, Non-Condensing
Vibration 0.5G, Max / 10-60 Hz
Elevation 3300 ft. without derating
Max source fault current 5 Kamps
Enclosure rating UL Type 4, No Direct Sunlight
