MOTOR CONTROl VIA KEYPAD
Action Description Display Comments
Press Menu Displays top level menu options.
STATUS
QUICK SETUP
PROGRAMMING
EVENT LOG
DIAGNOSTICS
DISPLAY OPTIONS
KCABGAID
Press or to move cursor over
the “EVENT LOG” selection.
Press Enter to view the event log.
Event Log Display
LOW INITIAL BUS
0 Date
Time
Entry #
0-9
HH:MM
Displays error name,
Entry # and time the
error occurred.
DD/MM/YY
EV. LOG
ECARTSUTATS
LOW INITIAL BUS
0 4-Jul-06 09:35:00
LOCALSTOP
Press or to view next entry.
Press R to display Trace menu.
Press A to return to Status Menu.
Troubleshooting Guide
The RediFlo VFD requires very little maintenance and should provide years of trouble free operation when
installed and applied correctly. Occasional visual inspection and cleaning should be considered to ensure tight
wiring connections and to remove dust, dirt, or foreign debris which can reduce heat dissipation. Operational
failures or warnings called “Faults” are displayed on the keypad display as they occur. A log of these faults and
the time each occurred is kept in the Event Log.
Event Log
Press the Menu key, select Event Log and press Enter.
If an error is displayed during operation, press the “Help” key to learn more about the error. If more than one
error was logged, access the Event Log and examine each error entry at the time of the event to learn more
about the error.
