3.1.2 Highest tapping point for SBA pumps
Install SBA pumps so that the height between the
pump and the highest tapping point does not exceed
these values:
SBA 3-35: 13 m.
SBA 3-45: 20 m.
Max.
13 m/43 ft
Max.
20 m/66ft
SBA 3-35 SBA 3-45
TM067648
Highest tapping point for SBA
Related information
8.4 Frequent starts and stops.
3.1.3
Minimum space
Pumps installed with a float switch require a free
space between the float switch and the wall to ensure
free movability.
Pumps with side inlet require a free space between
the floating inlet strainer and the wall.
If you install the pump in a well or tank, the minimum
free space must be as shown in the figure below.
Pumps installed without a float switch require a space
that corresponds to the physical dimensions of the
pump.
SB and SBA pump with a float switch and side
inlet
TM082302
Minimum space for SB and SBA pump in a well or
tank
7
English (GB)
