Grundfos Sololift2 WC-1 - Technical Specifications

English (GB)
11
8. Technical data
Supply voltage
1 x 220-240 V - 10 %/+ 6 %, 50 Hz.
Power consumption
Max. 620 W.
Power factor
Cos φ 0.87/0.92.
Speed
2800 min
-1
.
Rated current
3.0 A.
Insulation class
F.
Flow rate
Max. 149 l/min.
System pressure
Max. 8.5 m.
Supply cable
1.5 m, 0.75 mm
2
(H05VV-F-3G).
Net weight
7.3 kg.
Start and stop levels
Start: 72 mm above bottom.
Stop: 52 mm above bottom.
Liquid temperature
Max. 50 °C.
Ambient temperature
+5 °C to +35 °C.
Duty
S3 - 50 % - 1 min. (30 sec. on; 30 sec. off).
Marking
Approvals
Àß56
