Fig. 1 Installation example with tank in a pit and with a controller. The diaphragm pump is not shown.
Fig. 2 Installation example with tank directly mounted on basement floor (the diaphragm pump is not
shown)
TM065789 0216
Pos. Description
1 Isolating valve, inlet
2 Controller
3 Drainage pump
4
Non-return valve,
discharge
5
Isolating valve,
discharge
6 Venting pipe
6
2
3
4
5
1
TM065790 0216
Pos. Description
1 Isolating valve, inlet
3 Drainage pump
4
Non-return valve,
discharge
5
Isolating valve,
discharge
6 Venting pipe
16
3
4
5
