Grundfos UP 20 - 14 BX User Manual

UP 15 - 14 B UP 20 - 14 BX
BT
BU
BUT
BXT
BXU
BXUT
16
L L
Replacement
PUMPS L 80 110
BUDERUS
BUZ15 80 OK
BU-Z15A 15C 140 + 96 43 39 13
EMB
NWS 20-6 140 + 96 43 39 13
GRUNDFOS
UP 15-13 B (U) 86 OK
UP 15-13 BX (U) 130 + 96 43 39 04
UP 20-07N, UP 20-15N 150 + 96 43 39 11 + 96 43 65 59
KSB
R12-1E 140 + 96 43 39 13
Riotherm C12/15 (T) 150 + 96 43 39 11 + 96 43 65 59
LOEWE
C151 (U) 86 OK
C151 X (U) 130 + 96 43 39 04
SPECK
BN 20/11, 20/22 150 + 96 43 39 11 + 96 43 65 59
VORTEX
BW(Z) 150, 151 R
1
/
2
”80 OK
BW(Z) 152, 153 R
1
/
2
”80 OK
BW(Z) 150, 151 V 110 OK
BW(Z) 152, 153 V 110 OK
303_298_comfort_eu.qxd 09/05/01 21:05 Side 16

Grundfos UP 20 - 14 BX Specifications

General

Model	UP 20-14 BX
Category	Water Pump
Max Head	14 m
Voltage	230 V
Frequency	50 Hz
Port-to-port length	180 mm
Maximum operating pressure	10 bar
Enclosure class	IP44
Insulation class	F
Type	Circulating pump
Connection Size	1 inch
Approvals	CE
Installation	In-line
Material	Stainless steel
