Allgemeiner Teil / General Section K-CDP 65
1-2 GRUNDIG Service
Es gelten die Vorschriften und Sicherheitshin-
weise gemäß dem Service Manual "Sicherheit",
Sach-Nummer 72010-800.00, sowie zusätzlich
die eventuell abweichenden, landesspezifischen
Vorschriften!
The regulations and safety instructions shall be
valid as provided by the "Safety" Service Manual,
part number 72010-800.00, as well as the
respective national deviations.
GB
Table of Contents
Page
General Section .....................................1-2…1-5
Test Equipment / Jigs .................................................................. 1-2
Service Hints ................................................................................ 1-2
Specifications ............................................................................... 1-2
Operating Instructions ................................................................. 1-3
Disassembly Instructions ............................................................ 1-5
Adjustment Procedures................................. 2-2
Layout of the PCB
and Circuit Diagram ............................3-1…3-9
Layout of the PCB ........................................................................ 3-1
Circuit Diagram ............................................................................ 3-3
IC -Description ............................................................................. 3-5
Exploded View and
Spare Parts List ....................................4-1…4-3
Exploded View ............................................................................. 4-1
Spare Parts List ........................................................................... 4-2
General Part
Test Equipment / Aids
Oscilloscope, DC Voltmeter, AF Voltmeter, Test CD Part No.: 72008-
376.00
Please note the Grundig Catalog "Test and Measuring Equipment"
obtainable from:
Grundig electronics GmbH
Würzburger Str. 150, D-90766 Fürth/Bay.
Tel.0911/703-0, Telefax 0911/703-4479
Technical Specifications
Frequency response .................................................... 20-20.000 Hz
D/A conversion.......................................... 1bit linear 4 fs digital filter
Output (at 4.5 V input level) .................................................. 500 mV
Line output ............................................................... stereo mini-jack
Power Supply:
AC: using the AC adaptor 230 V
DC: two LR 6 (AA) alkaline-batteries or accumulators
Power consumption ........................................................... 1.0 W DC
Dimensions (WxHxD).............. Approx. 131 mm x 29 mm x 153 mm
Weight ............................................................. Approx. 300g (10 oz)
Supplied accessories .......... AC power adaptor, Stereo headphones
D
Inhaltsverzeichnis
Seite
Allgemeiner Teil....................................1-2…1-5
Meßgeräte / Meßmittel ................................................................. 1-2
Servicehinweise ........................................................................... 1-2
Technische Daten ........................................................................ 1-2
Bedienhinweise ........................................................................... 1-3
Ausbauhinweise .......................................................................... 1-5
Abgleich .......................................................... 2-1
Platinenabbildung
und Schaltplan ......................................3-1…3-9
Platinenabbildung ........................................................................ 3-1
Schaltplanabbildung.................................................................... 3-3
IC-Beschreibung ......................................................................... 3-5
Explosionszeichnung
und Ersatzteilliste .................................4-1…4-3
Explosionszeichnung .................................................................. 4-1
Ersatzteilliste ............................................................................... 4-2
Allgemeiner Teil
Meßgeräte / Meßmittel
Oszilloskop, DC-Voltmeter, NF-Voltmeter, Test-CD Sach-Nr.: 72008-
376.00
Beachten Sie bitte das Grundig Meßtechnik-Programm, das Sie unter
folgender Adresse erhalten:
Grundig electronics GmbH
Würzburger Str. 150, D-90766 Fürth/Bay.
Tel.0911/703-0, Telefax 0911/703-4479
Technische Daten
Frequenzgang ............................................................. 20-20.000 Hz
D/A -Umsetzung.................................... 1 Bit linear 4 fs digital Filter
Ausgangspegel (4,5V Eingang) ............................................ 500 mV
Line Ausgang ........................................................... Stereo mini jack
Stromversorgung:
AC: Netzadapter 230 V
DC: 2 LR 6 (AA) Alkali-Batterien oder Akkus
Leistungsaufnahme........................................................... 1,0 W DC
Abmessungen (BxHxT) .................. ca. 131 mm x 29 mm x 153 mm
Gewicht ................................................................................ca. 300g
Zubehör (mitgeliefert)....................... Netzadapter, Stereo Kopfhörer
