PA 1 Ersatzteilliste / Spare Parts List
GRUNDIG Service 4 - 3
ÄNDERUNGEN VORBEHALTEN SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
2 / 96 PA 1 MAX
D
Btx
*
32700 #
POS. NR. ABB. SACHNUMMER ANZ.
POS. NO.
FIG. PART NUMBER QUA.
BEZEICHNUNG
DESCRIPTION
D
GB
SACH-NR. / PART NO.: 9.79403-8151
BESTELL-NR. / ORDER NO.: G.LF 1451
A001.000 1 75954-034.37 GEHAEUSEVORDERTEIL CABINET FRONT
A003.000 1 75954-034.38 CASSETTENSCHWENKER CASSETTE SWIVEL
A004.000 1 75952-042.08 ZAHNRAD, CASSETTENDECKEL GEAR WHEEL, CASS.LID
A005.000 1 75954-034.40 FEDER CASSETTE SPRING CASSETTE
A006.000 1 75954-034.41 LINSE DISPLAY LENS DISPLAY
A007.000 1 75954-034.42 KNOPF KNOB
A008.000 1 75954-034.43 KNOPF LAUTSTAERKE KPL. KNOB VOLUME CPL.
A009.000 1 75954-034.44 KNOPF INFO KNOB INFO
A010.000 1 75954-034.45 KNOPF AM /FM KNOB AM/FM
A011.000 1 75954-034.46 KNOPF ABSTIMMUNG TUNING CPL.
A012.000 1 75954-034.47 KNOPF CD FUNKTION KNOB CD FUNCTION CPL.
A013.000 1 75954-034.48 KNOPF WIEDERGABE KNOB PLAYBACK
A014.000 1 75954-034.50 KNOPF EQUALIZER EQUALIZER CPL.
A015.000 1 75954-034.51 FENSTER DISPLAY WINDOW DISPLAY
A016.000 1 75954-034.52 KNOPF GUMMI KNOB RUBBER
A017.000 1 75954-034.53 TUER CASSETTE DOOR CASS.
A018.000 1 75954-034.54 LINSE CASSETTE LENS CASS.
A020.000 1 75954-034.39 TUER CD DOOR CD
A022.000 1 75954-034.55 LINSE CD LENS CD
A024.000 1 75954-034.56 FEDER CD SPRING CD
A026.000 1 75954-034.57 FEDER SPRING
A028.000 1 75954-034.58 KNOPF POWER KNOB POWER
A029.000 1 75954-034.59 KNOPF CD KNOB CD
A030.000 1 75954-034.60 ABSORBER ABSORBER
A031.000 1 75954-020.53 CD LAUFWERK CDM 12,3 BLT CD TAPE DRIVE
A033.000 1 75952-042.05 BATTERIEFEDER +- BATTERY SPRING +-
A035.000 1 75954-034.61 BATTERIEEINSCHUBGEHAEUSE BATTERY INSERT HOUSING
A036.000 1 75954-034.62 BATTERIEFACHDECKEL BATTERY COMP. COVER
A037.000 1 75954-034.63 FUSS LINKS FOOT LEFT
A038.000 1 75954-034.64 FUSS RECHTS FOOT RIGHT
A039.000 1 75954-034.89 LAUTSPRECHER 4 OHM LOUDSPEAKER 4 OHM
A040.000 1 75954-034.88 SOUND TUBE SOUND TUBE
KEIN E-TEIL NO SPARE PART
A040.100 19144-121.61 LAUTSPRECHER MITTELTON LOUDSPEAKER - MID RANGE
A040.200 19115-010.03 HOCHTONFOLIENKALOTTE TWEETER FOIL DOME
A040.300 29628-804.02 LS-GITTER ROHR OFB LS-GRILLE
A040.400 29628-805.01 ZUSATZTEIL F.LS-MONTAGE SUPPLEMENTARY
A040.500 29628-803.01 SOUNDROHR OFB SOUND TUBE
A040.600 8116-980-400 SCHRAUBE ZYLSHR K40X20 ST KLEV1 SCREW ZYLSHR K40X20 ST KLEV1
A040.700 29628-826.01 SOUND ROHREINLAGE SOUND TUBE INSERT
A041.000 1 75954-034.65 GEHAEUSEBODEN KPL. CABINET BOTTOM ASSY
A042.000 1 75954-034.66 LAUTSPRECHERGITTER SPEAKER GRILLE
A044.000 1 75954-034.67 FEDER CASSETTE KNOPF SPRING CASS. KNOB
A047.000 1 75954-034.68 KNOPF CASS. AUFNAHME KNOB CASS. RECORD
A048.000 1 75954-034.69 KNOPF CASS. WIEDERGABE KNOB CASS. PLAYBACK
A049.000 1 75954-034.70 KNOPF CASS. RUECKSPUL KNOB CASS. REWIND
A050.000 1 75954-034.71 KNOPF CASS. VORSPUL KNOB CASS. WIND
A051.000 1 75954-034.72 KNOPF CASS. AUSWURF/STOP KNOB CASS. EJECT/STOP
A052.000 1 75954-034.73 KNOPF CASS. PAUSE KNOB CASS. PAUSE
A053.000 1 75954-034.74 LAUFWERK KPL. DRIVE MECHANISM CPL.
A054.000 1 75954-034.75 FEDER (BATTERIESCHUTZ) SPRING (BATTERYSAFETY)
A058.000 1 75954-034.76 KONTAKT BATTERIE CONTACT BATTERY
A059.000 1 75954-034.77 FEDER BATTERIE SPRING BATTERY
A060.000 1 75954-034.78 ABDECKUNG LINKS COVER LEFT
A061.000 1 75954-034.79 ABDECKUNG RECHTS COVER RIGHT
A066.000 1 75954-034.80 KNOPF HEBEL LINKS KNOB LEVER LEFT
A069.000 1 75954-034.81 KNOPF HEBEL RECHTS KNOB LEVER RIGHT
