Ersatzteilliste / Spare Parts List PA 1
4 - 4 GRUNDIG Service
ÄNDERUNGEN VORBEHALTEN SUBJECT TO ALTERATION
POS. NR. ABB. SACHNUMMER ANZ.
POS. NO.
FIG. PART NUMBER QUA.
BEZEICHNUNG
DESCRIPTION
D
GB
A070.000 1 75954-034.90 HALTER ANTENNE HOLDER ANTENNA
A073.000 1 75954-034.82 FUSS VORNE FOOT FRONT
A074.000 S1 75954-034.83 NETZTRAFO POWER TRANSFORMER
A075.000 1 75954-034.84 TELESKOPANTENNE TELESCOPIC ANTENNA
A081.000 1 75954-034.85 GRIFF KPL. HANDLE CPL.
A082.000 1 75954-034.86 GEHAEUSEOBERTEIL KPL. CABINET TOP CPL.
A105.000 S 75950-004.10 NETZKABEL POWER CABLE
A110.000 75954-034.87 FERNBEDIENUNG RC6878/18 P REMOTE CONTROL RC6878/18P
A111.000 75954-034.94 12V-AUTOANSCHLUßKABEL 12V CAR CONNECTION CABLE
A111.100 S 75954-034.93 SICHERUNG 5A/F 250VAC 6,3X32 FUSE 5A/F 250VAC 6,3X32
72010-746.70 BEDIENUNGSANLEITUNG 10SPR INSTRUCTION MANUAL 10SPR.
72010-748.40 SERVICE MANUAL SERVICE MANUAL
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
TUNER
CD 102 75954-034.12 DIODE SVC 201 SPA
CD 103 75954-010.18 DIODE SVC 321
CD 104 75954-034.12 DIODE SVC 201 SPA
CD 105 75954-010.18 DIODE SVC 321
CT 102 75954-034.03 TRIMMER 10 PF
CT 103 75954-010.14 TRIMMER 4,5/20 PF
D 104 75952-030.43 SI-DIODE 1 N 4148
D 110 75952-030.43 SI-DIODE 1 N 4148
D 204 75954-034.16 SI-DIODE ISS119
DZ 101 8309-720-035 Z DIODE 3,6 B 0,5W
F 101 75954-034.04 FILTER BPMB8
F 103 75954-034.08 SPULE FM IFT 7X7MM
F 104 75954-034.10 SPULE AM IFT 7X7 MM
F 105 75954-029.22 SPULE MW ANT 19202-702.12
F 106 75954-034.05 FILTER KERAMIK 450 A
F 107 75954-034.06 FILTER KERAMIK CR.
F 108 75954-034.09 SPULE FM IFT 7X7 MM
F 109 75954-034.07 SPULE MW OSC 7X7MM
IC 101 75987-487.30 IC KIA 6067
IC 102 8305-204-700 IC LM 7000 SANYO
IC 103 75954-034.13 IC KIA 78S05P (AT)
IC 104 8305-205-729 IC MC 78 L 08 ACPRA
IC 105 8305-204-833 IC LM 833 N/ELDB 793 NSC
L 102 75954-034.11 SPULE FM OSC 2,5T E525
L 103 75954-034.11 SPULE FM OSC 2,5T E525
L 104 8140-526-412 DR AX 0411 10UH
L 205 75954-034.15 DROSSEL 820 UH +-10%
L 206 75954-034.92 SPULE 5T
QZ 201 75954-034.01 QUARZ 7,2 MHZ
R 124 75954-034.02 REGLER 10 KOHM
T 101 75987-356.91 TRANS.2 SC 1815 Y GR
T 102 75985-907.00 TRANS.2 SC 380 TM O
T 103 75986-259.00 TRANS.2 SA 1015 Y
T 104 75986-259.00 TRANS.2 SA 1015 Y
T 105 75986-259.00 TRANS.2 SA 1015 Y
T 106 75987-356.91 TRANS.2 SC 1815 Y GR
T 107 75986-259.00 TRANS.2 SA 1015 Y
T 108 75987-356.91 TRANS.2 SC 1815 Y GR
T 201 75987-414.51 TRANS.2 SC 1923 R
T 202 75987-414.51 TRANS.2 SC 1923 R
T 203 75985-907.00 TRANS.2 SC 380 TM O
T 204 75987-414.51 TRANS.2 SC 1923 R
T 205 75985-907.00 TRANS.2 SC 380 TM O
T 206 75987-356.91 TRANS.2 SC 1815 Y GR
T 207 75986-259.00 TRANS.2 SA 1015 Y
T 208 75986-259.00 TRANS.2 SA 1015 Y
T 209 75987-356.91 TRANS.2 SC 1815 Y GR
T 212 75986-259.00 TRANS.2 SA 1015 Y
BEDIENPLATTE/
CONTROLL BOARD
CR 701 75952-030.19 CER RESONATOR 4,00 MHZ
D 702 75952-030.43 SI-DIODE 1 N 4148
D 703 75952-030.43 SI-DIODE 1 N 4148
D 704 75952-030.43 SI-DIODE 1 N 4148
D 705 75952-030.43 SI-DIODE 1 N 4148
D 706 75952-030.43 SI-DIODE 1 N 4148
D 707 75952-030.43 SI-DIODE 1 N 4148
IC 700 75954-010.41 IR EMPFAENGER
IC 701 75954-034.21 IC U-P M3822XMX-XXX 80P6N
IC 702 75954-010.39 IC X 24 C 04 P EPROM
IC 703 75954-034.22 IC M62007L SIP5
L 701 8140-525-974 DR AX 0411-GA 22UH
LCD 301 75954-034.20 LCD MGRT-0025 (RO)-DP
LED 701 75954-034.19 LED RLL3N4PD - N33
Q 701 8303-272-328 TRANS.BC 328-25
Q 702 75952-030.41 TRANS.BC 338-25
Q 703 8303-272-328 TRANS.BC 328-25
Q 704 75952-030.41 TRANS.BC 338-25
Q 705 75987-356.91 TRANS.2 SC 1815 Y GR
Q 706 75954-034.23 SI-PNP TRANS 2SA1160B
S 101-S104 75952-030.08 TAKTSCHALTER
S 109-S118 75952-030.08 TAKTSCHALTER
VR 701 75954-034.17 POTI SLIDE S3018L601A
VR 702 75954-034.17 POTI SLIDE S3018L601A
