PA 1 Ersatzteilliste / Spare Parts List
GRUNDIG Service 4 - 5
ÄNDERUNGEN VORBEHALTEN SUBJECT TO ALTERATION
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
VR 703 75954-034.17 POTI SLIDE S3018L601A
VR 750 75954-034.18 POTI ROT100KBX2 RK16812MG
HAUPTPLATTE/
MAIN BOARD
C 401 75954-010.26 ELKO 4700UF 35V 20%
C 407 75954-029.03 ELKO 10000 UF 20% 25V
CT 414 S 75954-034.25 NETZBUCHSE AC SKT HSC1466
D 401 75954-029.09 DIODE BR 104
D 404 8309-720-046 Z DIODE 4,7 B 0,5W
D 405 75952-030.43 SI-DIODE 1 N 4148
D 406 75952-030.43 SI-DIODE 1 N 4148
D 409 75954-010.32 DIODE 1 N 5401
D 410 75952-030.46 Z DIODE 3,9 V 500MW
D 421 75952-030.43 SI-DIODE 1 N 4148
D 422 75952-030.43 SI-DIODE 1 N 4148
D 423 8309-720-067 Z DIODE 6,8 B 0,5W
D 424 75952-030.43 SI-DIODE 1 N 4148
D 425 75952-030.43 SI-DIODE 1 N 4148
D 426 75952-030.43 SI-DIODE 1 N 4148
D 427 75952-030.43 SI-DIODE 1 N 4148
D 431 8309-701-037 Z DIODE BZX 83 C6 V2 SES
D 501 75952-030.43 SI-DIODE 1 N 4148
F 401 S 75954-034.29 SICHERUNG T1,0A TR5-T193
F 402 S 75954-034.28 SICHERUNG 4A TR-5/19372C
F 403 S 75954-034.29 SICHERUNG T1,0A TR5-T193
F 404 S 75954-034.28 SICHERUNG 4A TR-5/19372C
IC 401 75954-015.57 IC MC 78M05CT
IC 402 75954-034.30 IC 78L09BP (AT)
IC 501 75954-029.05 IC SOUND PROC. M62413
IC 502 8305-204-833 IC LM 833 N/ELDB 793 NSC
IC 503 75954-029.06 IC TDA 7370
IC 504 75954-034.24 IC TDA 7396
IC 505 8305-204-833 IC LM 833 N/ELDB 793 NSC
L 401 75952-030.62 AC-FILTER
R 414 S 75954-012.14 SI.-WIDERST.1,0
REL 401 S 75954-034.27 RELAIS 12V/12A
REL 402 S 75954-034.27 RELAIS 12V/12A
S REC 75954-034.33 SCHALTER 6P2T
S 401 S 75952-030.12 NETZSCHALTER
S 402 S 75954-034.26 SCHALTER
T 401 75952-030.39 TRANS.BC 548 B
T 402 75952-030.39 TRANS.BC 548 B
T 403 75987-356.91 TRANS.2 SC 1815 Y GR
T 404 75954-034.23 SI-PNP TRANS 2SA1160B
T 405 75987-470.50 TRANS.2 SC 2236 O
T 406 75987-356.91 TRANS.2 SC 1815 Y GR
T 407 75987-356.91 TRANS.2 SC 1815 Y GR
T 422 75954-015.33 TRANS. BC 338-40 (TAPE)
T 423 75954-015.33 TRANS. BC 338-40 (TAPE)
T 431 8303-203-548 TRANS BC548A
T 432 75987-470.50 TRANS.2 SC 2236 O
T 501 75952-030.39 TRANS.BC 548 B
T 502 75987-356.91 TRANS.2 SC 1815 Y GR
T 602 75987-356.91 TRANS.2 SC 1815 Y GR
CD-PLATTE/CD BOARD
D 801 75952-030.46 Z DIODE 3,9 V 500MW
IC 801 75954-029.02 IC M 3818M8-175PF
IC 802 8305-341-301 IC TDA 1301 T/N1
IC 804 75954-012.19 IC TDA 1302 T
IC 805 75952-030.24 IC LM 833 N
IC 806 75953-701.04 IC TDA 1311 AT / N2
IC 807 75953-701.75 IC TDA 7073 A / N2
IC 808 75953-701.75 IC TDA 7073 A / N2
IC 809 75953-701.03 IC SAA 7345 GP / M5
KR 801 75951-004.26 QUARZ 16,934 MHZ
R 812 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
R 820 S 8700-229-001 KSW NB 0207 1 OHM LCA DR
R 821 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
R 826 S 8700-229-001 KSW NB 0207 1 OHM LCA DR
R 842 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
R 846 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
R 853 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
R 875 S 75952-030.91 KSW SI A 4,7 OHM 5% GA
S 105 75952-030.08 TAKTSCHALTER
S 106 75952-030.08 TAKTSCHALTER
S 107 75952-030.08 TAKTSCHALTER
S 108 75952-030.08 TAKTSCHALTER
SW 701 75954-034.32 SCHALTER ESE11SV1
T 804 75952-030.39 TRANS.BC 548 B
T 805 75952-030.39 TRANS.BC 548 B
T 806 75952-030.39 TRANS.BC 548 B
CASS.-PLATTE/CASS. BOARD
D 300 75952-030.43 SI-DIODE 1 N 4148
D 301 75952-030.43 SI-DIODE 1 N 4148
D 302 75952-030.43 SI-DIODE 1 N 4148
D 303 75954-034.91 Z-DIODE 2,1V/500MW
IC 300 75987-478.68 IC AN 7312
IC 301 8305-205-729 IC MC 78 L 08 ACPRA
L 301 75954-034.34 DROSSEL 1 MH +-10%
L 302 75954-034.31 DROSSEL 279 UH +-10%
Q 300 8302-200-254 BC 548B/C SIE/VAL/TFK/ITT
Q 301 8302-200-254 BC 548B/C SIE/VAL/TFK/ITT
Q 302 75952-030.38 TRANS. BC 558 B
Q 303 8302-200-254 BC 548B/C SIE/VAL/TFK/ITT
Q 304 8302-200-254 BC 548B/C SIE/VAL/TFK/ITT
Es gelten die Vorschriften und Sicherheitshin-
weise gemäß dem Service Manual "Sicherheit",
Sach-Nummer 72010-800.00, sowie zusätzlich
die eventuell abweichenden, landesspezifischen
Vorschriften!
The regulations and safety instructions shall be
valid as provided by the "Safety" Service Manual,
part number 72010-800.00, as well as the
respective national deviations.
( )
