RR 710 CD / RR 750 CD Ersatzteillisten und Explosionszeichnungen / Spare Parts Lists and Exploded Views
GRUNDIG Service 4 - 2
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
Q 106 75954-047.24 TRANSISTOR 9012H
Q 203 75952-500.07 TRANS.9015 C
Q 204 75952-500.07 TRANS.9015 C
Q 205 75952-500.06 TRANS.9014 C
Q 209 75952-500.06 TRANS.9014 C
Q 210 75952-500.06 TRANS.9014 C
Q 211 8302-991-044 FE-TRANS.2 SK 544 E
Q 212 75952-500.06 TRANS.9014 C
Q 301 75954-047.25 TRANSISTOR 2SC 1417F
Q 303 75952-500.06 TRANS.9014 C
Q 304 75952-500.07 TRANS.9015 C
Q 305 75952-500.07 TRANS.9015 C
Q 306 75952-500.07 TRANS.9015 C
Q 307 75952-500.06 TRANS.9014 C
Q 308 75952-500.06 TRANS.9014 C
Q 309 75954-047.25 TRANSISTOR 2SC 1417F
Q 310 75952-500.07 TRANS.9015 C
Q 311 75952-500.06 TRANS.9014 C
Q 312 75952-500.06 TRANS.9014 C
Q 313 75952-500.06 TRANS.9014 C
Q 401 75952-500.06 TRANS.9014 C
Q 402 75952-500.06 TRANS.9014 C
Q 403 75952-500.06 TRANS.9014 C
Q 404 75952-500.06 TRANS.9014 C
Q 501 75952-500.06 TRANS.9014 C
Q 503 75985-267.00 TRANS.2 SC 2001
Q 601 75987-356.91 TRANS.2 SC 1815 Y GR
Q 602 75987-356.91 TRANS.2 SC 1815 Y GR
Q 603 75954-020.09 TRANS. SS8550 C
Q 604 75954-020.09 TRANS. SS8550 C
Q 605 75952-500.06 TRANS.9014 C
Q 606 75954-046.21 TRANSISTOR 8050 B
Q 607 75952-500.06 TRANS.9014 C
Q 608 75954-046.21 TRANSISTOR 8050 B
Q 610 75954-020.09 TRANS. SS8550 C
Q 611 75987-515.88 TRANS.9013 G
Q 612 75952-500.06 TRANS.9014 C
Q 613 75952-500.06 TRANS.9014 C
Q 652 75987-356.91 TRANS.2 SC 1815 Y GR
Q 653 75987-356.91 TRANS.2 SC 1815 Y GR
SW 101 75954-021.04 SCHALTER
SW 201 75954-021.14 TAKTSCHALTER
SW 202 75954-021.14 TAKTSCHALTER
SW 203 75954-021.14 TAKTSCHALTER
SW 204 75954-021.14 TAKTSCHALTER
SW 205 75954-021.14 TAKTSCHALTER
SW 206 75954-021.14 TAKTSCHALTER
SW 207 75954-021.14 TAKTSCHALTER
SW 208 75954-021.14 TAKTSCHALTER
SW 209 75954-021.14 TAKTSCHALTER
SW 210 75954-021.14 TAKTSCHALTER
SW 401 75954-047.40 SCHALTER SST-43D01-G10
SW 402 75954-046.24 TAKTSCHALTER PUSH SW. PSA
SW 403 75954-046.24 TAKTSCHALTER PUSH SW. PSA
SW 404 75954-046.24 TAKTSCHALTER PUSH SW. PSA
SW 405 75954-021.14 TAKTSCHALTER
SW 406 75954-021.14 TAKTSCHALTER
SW 501 75954-035.84 SCHALTER 9P2T
SW 502 75954-046.24 TAKTSCHALTER PUSH SW. PSA/
SWITCH
T 1
S 75954-047.26 TRANSFORMATOR AC EI 48
T 301 75954-047.34 SPULE OA-817968/COIL
T 302 75954-047.35 SPULE 817961/COIL
T 303 75954-047.36 SPULE 818154/COIL
TC 301 8699-998-116 TR.53 4,5-20PF
TC 302 75954-034.03 TR. 10PF
TC 303 75954-046.32 TRIMMER 40PF 2 LEGS
TC 304 75954-046.32 TRIMMER 40PF 2 LEGS
U 501 75954-047.27 IC BA 3313L
VR 101 75954-047.39 REGLER KVSF637AB 5 K
VR 102 8792-002-164 ESTR.S6 100 KOHM LIN
VR 401 75954-047.38 REGLER F-164KP-1B50KL15F
VR 402 75954-047.37 REGLER F-167KP-1A50K L20F/
CONTROL
X 101 75953-033.32 QUARZ 16,9344 MHZ H
X 201 75953-701.33 QUARZ 7,200 MHZ
ZD 601 8309-720-091 Z-DIODE 9,1 C 0,5W
ZD 602 8309-701-037 Z-DIODE BZX83C6V2 SES/SI
ZD 603 8309-701-037 Z-DIODE BZX83C6V2 SES/SI
CF 301 8602-822-190 CER.FIL.190
CF 302 75954-047.15 CER. FIL. LPU 450 B
CF 303 75986-436.50 FILTER
CF 304 75954-047.16 FILTER U. DIS. FM 10,7MS
D 101 8309-215-045 DIODE 1N4148
D 202 8309-215-045 DIODE 1N4148
D 207 8309-215-045 DIODE 1N4148
D 208 8309-215-045 DIODE 1N4148
D 209 8309-215-045 DIODE 1N4148
D 210 8309-215-045 DIODE 1N4148
D 211 8309-215-045 DIODE 1N4148
D 212 8309-215-045 DIODE 1N4148
D 213 8309-215-045 DIODE 1N4148
D 214 8309-215-045 DIODE 1N4148
D 217 8309-215-045 DIODE 1N4148
D 218 8309-215-045 DIODE 1N4148
D 219 8309-215-045 DIODE 1N4148
D 220 8309-215-045 DIODE 1N4148
D 221 8309-215-045 DIODE 1N4148
D 223 8309-215-045 DIODE 1N4148
D 301 8309-215-045 DIODE 1N4148
D 302 8309-215-045 DIODE 1N4148
D 303 8309-215-045 DIODE 1N4148
D 304 75954-047.17 DIODE VAR SVC 201Y
D 305 75954-047.17 DIODE VAR SVC 201Y
D 306 8309-215-045 DIODE 1N4148
D 307 75954-047.18 DIODE VAR ISV 149
D 310 75954-047.18 DIODE VAR ISV 149
D 311 8309-707-012 Z-DIODE ZPD4,7 ITT
D 312 8309-215-045 DIODE 1N4148
D 313 8309-215-045 DIODE 1N4148
D 601 8309-215-045 DIODE 1N4148
D 602 8309-215-045 DIODE 1N4148
D 603 8309-215-045 DIODE 1N4148
D 604 8309-215-045 DIODE 1N4148
D 605 8309-215-045 DIODE 1N4148
D 606 8309-215-045 DIODE 1N4148
D 607 8309-215-045 DIODE 1N4148
D 608 8309-215-045 DIODE 1N4148
D 609 8309-215-045 DIODE 1N4148
D 610 8309-215-045 DIODE 1N4148
D 611 8309-215-045 DIODE 1N4148
D 612 8309-215-045 DIODE 1N4148
D 613 8309-215-045 DIODE 1N4148
D 614 8309-215-045 DIODE 1N4148
D 615 8309-215-045 DIODE 1N4148
D 801 8309-215-020 DIODE 1 N 4004 -GA
D 802 8309-215-020 DIODE 1 N 4004 -GA
D 803 8309-215-020 DIODE 1 N 4004 -GA
D 804 8309-215-020 DIODE 1 N 4004 -GA
F 801
S 8315-620-003 SI 5X20 T2A L 250V
IC 101 75954-047.19 IC BA 4560N
IC 102 75954-047.20 IC TC 9284 BF
IC 103 75954-047.21 IC TA 2065F
IC 104 75954-021.24 IC BA 6398 FP
IC 201 75954-047.22 IC TC 9309AF-119
IC 301 75952-500.18 IC TA 7358 AP
IC 302 75954-046.10 IC KA 22066
IC 601 75954-046.10 IC KA 22066
IC 602 75954-046.12 IC BA 5053
IC 603 75954-047.33 IC KIA 7808 PI
J 001
S 75954-021.44 NETZ BUCHSE/MAINS SOCKET
J 601 75954-021.70 KOPFHOERER BUCHSE/
EAR PHONE SOCKET
L 304 75954-047.30 SPULE MW/COIL
L 305 75954-047.31 SPULE LW 10MM/COIL
L 306 75954-047.32 SPULE DR. 6,8 MH/COIL
L 501 75954-021.10 DR 560UH RM2 RAD 3A 396N
L 502 75954-046.16 SPULE
1,5MH CW-152 KOHM/COIL
LCD 001 75954-047.23 DISPLAY LCD TCM714
LED 001 8309-944-406 LE DIODE TLHR 4405 TFK
MIC 501 75954-046.18 MIKROFON KOND. KUC 4023/
MICROPHONE
Q 101 75952-500.06 TRANS.9014 C
Q 102 75952-500.06 TRANS.9014 C
Q 103 75952-500.07 TRANS.9015 C
Q 104 75952-500.06 TRANS.9014 C
Q 105 75954-020.09 TRANS. SS8550 C
Ersatzteilliste
Spare Parts List
11 / 96
Btx
*
32700
#
POS. NR.
ABB.
SACHNUMMER ANZ.
POS. NO.
FIG.
PART NUMBER QTY.
BEZEICHNUNG
DESCRIPTION
D
GB
RR 710 CD
SACH-NR. / PART NO.:
BESTELL-NR. / ORDER NO.:
75.3121-1051
G.DG 6351
0001.000 1 75954-046.67 ABDECKBLENDE R COVER MASK R
0002.000 1 75954-046.96 LAUTSPRECHER GITTER L SPEAKER GRILLE L
0003.000 1 75954-047.41 TUER CASS DOOR CASS.
0004.000 1 75954-046.43 LINSE, TUER CASS. LENS DOOR CASS.
0005.000 1 75954-047.01 FRONTBLENDE FRONT MASK
0006.000 1 75954-046.57 2 LINSE, POWER LENS POWER
0007.000 1 75954-047.05 KNOPF, CD KONTROLL L2 KNOB, CD CONTROL L2
0008.000 1 75954-047.04 KNOPF, CD KONTROLL L1 KNOB, CD CONTROL L1
0011.000 1 75954-046.38 GEHAEUSEVORDERTEIL CABINET FRONT
0012.000 1 75954-046.58 KNOPF REC, CASS KNOB REC, CASS
0013.000 1 75954-046.59 KNOPF PLAY, CASS. KNOB PLAY, CASS
0014.000 1 75954-046.60 KNOPF REW CASS KNOB REWIND CASS
0015.000 1 75954-046.61 KNOPF FF, CASS KNOB FF, CASS
0016.000 1 75954-046.62 KNOPF STOP/EJEKT, CASS KNOB STOP/EJEKT, CASS
0017.000 1 75954-046.63 KNOPF PAUSE, CASS KNOB PAUSE, CASS
0020.000 1 75954-046.87 CASS LAUFW. TK20FX-S818-003 CASS. DRIVE MECHANISN TK20FX-S818-003
0024.000 1 75954-046.95 VOLUME KNOPF VOLUME KEY
0025.000 1 75954-046.75 KNOPF UBS KNOB UBS
0026.000 1 75954-047.08 KNOPF TON KNOB TONE
0027.000 1 75954-046.74 KNOPF, FUNKTIONSCHALTER KNOB FUNCTION SWITCH
0028.000 1 75954-046.42 CD KONSOLE CD DRAWER
0030.000 1 75954-047.03 ABDECKBLENDE L COVER MASK L
0032.000 1 75954-046.36 HALTER HOLDER
0033.000 1 75954-046.78 MAGNETHALTER MAGNET HOLDER
0034.000 1 75954-046.84 MAGNET MAGNET
0035.000 1 75954-047.09 TUER, CD DOOR, CD
0036.000 1 75954-046.46 HALTER, GRIFF L HOLDER, HANDLE L
0037.000 1 75954-046.50 HALTER, GRIFF R HOLDER, HANDLE R
0038.000 1 75954-046.55 GRIFF HANDLE
0040.000 1 75954-046.90 BATTERIE KONTAKT + BATTERY CONTACT +
0041.000 1 75954-046.37 TUER, BATTERIE DOOR, BATTERY
0046.000 1 75954-046.86 TELESKOPANTENNE TELESCOPIC ANTENNA
0047.000 1 75954-046.39 GEHAEUSERUECKTEIL REAR PANEL
0048.000 1 75954-046.91 BATTERIE KONTAKT +/- BATTERY CONTACT +/-
0060.000 1 75954-046.89 LAUTSPRECHER 4" 8 OHM LOUDSPEAKER 4" 8 OHM
0062.000 1 75954-046.83 FUSS, GUMMI FOOT RUBBER
0063.000 1 75954-047.13 FEDER, TUER CASS. SPRING, DOOR CASS.
0064.000 1 75954-047.06 KNOPF, CD KONTROLL R1 KNOB, CD CONTROL R1
0065.000 1 75954-047.07 KNOPF, CD KONTROLL R2 KNOB, CD CONTROL R2
0066.000 1 75954-046.44 LINSE DISPLAY LENS DISPLAY
0068.000 1 75954-046.78 MAGNETHALTER MAGNET HOLDER
0069.000 1 75954-046.54 HALTER B HOLDER B
0070.000 1 75954-046.53 DECKELBREMSE B LID BRAKE B
0071.000 1 75954-046.97 LAUTSPRECHER GITTER R SPEAKER GRILLE R
0072.000 1 75954-046.68 ZEIGER POINTER
0076.000 1 75954-046.88 CD-LAUFWERK CD-DRIVE MECHANISM UNIT
0078.000 1 75954-021.63 2 PUFFER/BLAU CUSHION/BLUE
0078.100 1 75954-021.64 2 PUFFER/SCHWARZ CUSHION/BLACK
0083.000 1 75954-046.85 SCHNAEPPER, SCHALTER CATCH SWITCH
0088.000 1 75954-046.52 HALTER A HOLDER A
0089.000 1 75954-046.51 DECKELBREMSE A LID BRAKE A
0090.000 1 75954-047.02 ABDECKBLENDE R COVER MASK R
0093.000 1 75954-046.35 ANDRUCKSCHEIBE B PRESSURE ROLLER B
0097.000 1 75954-047.14 FEDER, TUER CD SPRING, DOOR CD
0112.000
S
75987-453.17 NETZKABEL POWER CABLE
0113.000 75954-046.45 FERRIT STAB FERRITE BAR
72010-747.75 BEDIENUNGSANLEITUNG INSTRUCTION MANUAL
72010-751.75 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
C 218 8452-995-104 ELKO 1000UF 20% 16V
C 231 8452-995-104 ELKO 1000UF 20% 16V
C 601 8452-995-107 ELKO 2200UF 20% 16V
C 602 8452-995-107 ELKO 2200UF 20% 16V
C 607 75954-046.01 ELKO 2200 MFD 25V +/-20%
C 633 8452-995-107 ELKO 2200UF 20% 16V
C 634 8452-995-107 ELKO 2200UF 20% 16V
C 805 75954-010.28 ELKO 1000UF 25V +-20%
