GRUNDIG Service Xenaro AVR 4300 DD
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
LP-CHASSISMODUL
CHASSISBOARD
AUDIO
MATERIAL-NR. / PART NO.: 275990118700
ǵ
11 / 2003
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
275990118700 LP-CHASSISMODUL CHASSISBOARD
KEIN E-TEIL NO SPRE PART
CN 60 759550579000 PROTEKTOR 5A/250V 8A/125V
D 1 830921500300 DIODE 1 N 4002
D 2 833021514800 MELF DIODE 1N4148
D 3 830921500300 DIODE 1 N 4002 <<<
D 4 830921500300 DIODE 1 N 4002 <<<
D 5 833021514800 MELF DIODE 1N4148
D 6 830921500300 DIODE 1 N 4002 <<<
D 7 833021514800 MELF DIODE 1N4148
D 8 830921500300 DIODE 1 N 4002 <<<
D 9 759550725400 DIODE SR160 SHKY
D 10 759550725400 DIODE SR160 SHKY
D 11 759550725400 DIODE SR160 SHKY
D 12 830970102500 Z-DIODE BZX 55 C18
D 13 759550577400 Z-DIODE BZX55-C13V
D 14 833021514800 MELF DIODE 1N4148
D 15 833021514800 MELF DIODE 1N4148
D 17 830970102500 Z-DIODE BZX 55 C18
D 18 759550725400 DIODE SR160 SHKY
D 107 830921500300 DIODE 1 N 4002
D 112 759550577300 BRUECKENDIODE 1.5A 400V
D 301 759550725400 DIODE SR160 SHKY
D 302 759550725400 DIODE SR160 SHKY
D 303 759550725400 DIODE SR160 SHKY
D 304 759550725400 DIODE SR160 SHKY
D 306 759550725400 DIODE SR160 SHKY
F 1 S 759836610000 SICHERUNG T2A/250V QFS-C202
F 2 S 759550578900 SICHERUNG 10A/250V 5X20MM
F 3 S 759550578900 SICHERUNG 10A/250V 5X20MM
F 105 S 759836610000 SICHERUNG T2A/250V QFS-C202
F 106 S 759836610000 SICHERUNG T2A/250V QFS-C202
IC 1 759550578100 IC ML78L08A 8V 100MA
IC 2 759901001700 IC LM 317
IC 3 759550578400 IC SL4558D
IC 4 759550578400 IC SL4558D
IC 5 759550578400 IC SL4558D
IC 203 759550726400 SMD IC NJM2296M
IC 301 759550578400 IC SL4558D
IC 302 759550726300 IC NJM7912
IC 302L 759550578400 IC SL4558D
IC 303 759550579200 IC ML7812A 12V 1A
IC 303R 759550578400 IC SL4558D
IC 305 830520570300 IC MC7805CT
IC 306 759880752800 IC LM317T
IC 307 759880752800 IC LM317T
IC 401 759550578400 IC SL4558D
IC 402 759550578400 IC SL4558D
IC 403 759550578400 IC SL4558D
IC 404 759880657000 IC BH3544F
L 100 759550578000 SPULE SC1.0
L 101 759550578000 SPULE SC1.0
L 102 759550578000 SPULE SC1.0
L 103 759550578000 SPULE SC1.0
L 104 759550578000 SPULE SC1.0
Q 2 759550577600 FILTER 8050C 190MHZ
Q 4 759785731000 SMD TRANS. 2 SC 1623 L6
Q 5 759550577500 FILTER 9014C 200MHZ
Q 5 759550577500 FILTER 9014C 200MHZ
Q 6 759550577500 FILTER 9014C 200MHZ
Q 7 759785731000 SMD TRANS. 2 SC 1623 L6
Q 8 759550577900 FILTER 2SA812 180MHZ
Q 9 830970102500 Z-DIODE BZX 55 C18
Q 10 759785731000 SMD TRANS. 2 SC 1623 L6
Q 12 759872515800 TRANS 2SB772Q
Q 17 759785731000 SMD TRANS. 2 SC 1623 L6
Q 22 759550579100 QUARZ 100 MHZ BC 327
Q 81 759785731000 SMD TRANS. 2 SC 1623 L6
Q 82 759550577900 FILTER 2SA812 180MHZ
Q 83 759550152800 TRANS KTK117Y
Q 83 759550725600 SMD TRANS 2SC1623
Q 103 759550577500 FILTER 9014C 200MHZ
Q 305 759785731000 SMD TRANS. 2 SC 1623 L6
Q 308 759550577800 FILTER 9015C 200MHZ
Q 309 759785731000 SMD TRANS. 2 SC 1623 L6
QV 1 759785731000 SMD TRANS. 2 SC 1623 L6
QV 2 759785731000 SMD TRANS. 2 SC 1623 L6
QV 3 759785731000 SMD TRANS. 2 SC 1623 L6
QV 4 759785731000 SMD TRANS. 2 SC 1623 L6
QV 5 759785731000 SMD TRANS. 2 SC 1623 L6
QV 6 759785731000 SMD TRANS. 2 SC 1623 L6
QV 7 759785731000 SMD TRANS. 2 SC 1623 L6
QV 8 759785731000 SMD TRANS. 2 SC 1623 L6
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000000, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
national deviations.
RLY 1 759550578800 RELAIS 24VDC/8A 2P2T
RLY 2 759550578800 RELAIS 24VDC/8A 2P2T
RLY 3 759550578700 RELAIS 12VDC/1A 2P2T
RLY 4 759550578700 RELAIS 12VDC/1A 2P2T
RLY 5 759550578600 RELAIS 12VDC/1A 2P2T
RLY 104 759550578800 RELAIS 24VDC/8A 2P2T
U 1 759550578200 IC LM4765
U 2 759550578300 IC LM4701T
U 3 759550578200 IC LM4765
U 4 759550726500 SMD IC QFP M61516FP 7.1CH
