Gryphon Apex User Manual

27
Same features as Apex Stereo, except:
 128 very high current bipolar output transistors (64 per Mono channel)
 2,080,000μF (>2 Farad) capacitor bank (1,040,000uF per Mono channel)
 Four separate custom made 2000VA toroidal transformers (2 per Mono channel)
 One Gold-plated Neutrik XLR socket input signal pass-thru for each channel
 2 x 210W @ 8, 2 x 420W @ 4, 2 x 800W @ 2 and 2 x 1490W @ 1 at 115V/230Vac
 Output impedance: 0.015
 Bandwidth (-3dB): 0.3Hz to 330KHz
 Gain: +31,0dB
 Max. input level: 1,16Vrms
 Input Impedance, balanced (20-20000Hz): 20K
 Dimensions, WxHxD:59,3x37,1x88,6 cm, 202kg net.
Please also see following page.
 Shipping dimensions:104 x 80 x 67 cm, 265kg
 1 x 225W @ 8, 1 x 450W @ 4, 1 x 880W @ 2 and 1 x 1690W @ 1 at 115V/230Vac
 Output impedance: 0.010
 Bandwidth (-3dB): 0.3Hz to 330KHz
 Gain: +31,0dB
 Max. input level: 1,20Vrms
 Input Impedance, balanced (20-20000Hz): 10K
 Dimensions, WxHxD::59,3x37,1x88,6 cm, 202kg net. - each amplifier channel.
Please also see following page.
 Shipping dimensions for a pair: Two crates; each 104 x 80 x 67 cm, total 530kg
Note: Specifications can be changed without notice.
Specifications, Apex Stereo
Features, Apex Mono
Specifications, Apex Mono (one channel)
