4. Installation
PNEG-2381 2000 Series U-Trough Bin Sweep Auger Unload System (72' - 78') 29
5. See Figure 4AE-Figure 4AJ for position options.
Figure 4AE Note Slot Position (Back View)
Figure 4AF Note Slot Position (Back View)
Figure 4AG Note Slot Position (Back View)
Figure 4AH Less Aggressive (Front View)
Figure 4AI Neutral (Front View)
Figure 4AJ More Aggressive (Front View)
Ref # Description
19 Loosen this Nut
