Section 8
ASSEMBLY
Page 57
ITEM PART # QTY. DESCRIPTION
1 050322 1 SCREW IHHC 5/16"-24 X 9-3/4"
2 022129 22 WASHER LOCK M8-5/16"
3 049451 1 WASHER FLAT .406" I.D. X 1.62" O.D.
4 0C8096A 1 FAN, 8" CURVE BLADE, 16.5MM I.D.
5 0D8120 4 SCREW IHHC M8-1.25 X 260MM
6 0C2824 2 SCREW TAP-R #10-32 X 9/16"
7 066386 1 ASSEMBLY, BRUSH HOLDER
8 0D4217 1 CARRIER, REAR BEARING
9 073159 1 BEARING
10 0D4484H 1 ROTOR
11 0D4430H 1 STATOR
12 0D4216 1 ADAPTOR, ENGINE
13 048614 4 SCREW HHC 5/16"-24 X 3/4"
14 0D2588A 1 GASKET, FRONT DIVIDER
15 022131 4 WASHER FLAT 3/8"-M10
16 027028 4 NUT LOCK HEX 5/16"-18 NYLON INSERT
17 0D6832 1 BRACKET, ENGINE MOUNTING
18 022145 20 WASHER FLAT 5/16"
19 030231 3 SCREW HHC 5/16"-18 X 1-1/2"
20 0C3168 1 5/16" SPECIAL LOCK WASHER
21 022259 10 NUT HEX 5/16"-18
22 0C8565 1 SCREW SHC M8-1.25 X 18MM
23 0D8048 4 VIBRATION MOUNT
24 083512 6 SCREW HHTT M8-1.2 X 16 YC
25 0D6831 1 BRACKET, ALTERNATOR MOUNTING
26 029451 2.14' TAPE ELEC. UL FOAM 1/8" X 1/2"
27 0D6918 1 DUCT, ALTERNATOR AIR
28 0D2558 1 GASKET, ALTERNATOR DUCT
29 087680 2 NUT WING M6-1.0
30 0D7530 1 STUD, M6-1.0 OFFSET
31 0D9723 1 ELEMENT, AIR FILTER
32 0D4511 1 PRECLEANER, AIR
33 0D8451 1 WASHER FLAT .281" I.D. X 1.25" O.D.
34 022097 1 WASHER LOCK M6-1/4"
35 0D7440 1 MUFFLER
36 090388 2 SCREW HHTT M6-1.0 X 12 YC
37 0D7441 2 BOLT CARR 5/16"-18 X 2"
38 081105 2 NUT FLANG 5/16"-18 LOCK
39 089476 1 GASKET, EXHAUST
40 045771 1 NUT, HEX M8-1.25
41 022531 1 SCREW HHC 5/16"-18 X 1-3/4"
To Next Page
