Section 9
SPECIFICATIONS & CHARTS
Page 66
TORQUE SPECIFICATIONS
LONG BLOCK TORQUE REQUIREMENTS
HEAD BOLTS 22 ft-lbs (±5%)
GEAR COVER BOLTS 18 ft-lbs
CONNECTING ROD CAP BOLTS 10 ft-lbs
VALVE COVER BOLTS 48 in-lbs
ROCKER ARM JAM NUTS 96 in-lbs
OIL PRESSURE RELIEF COVER BOLT 50 in-lbs
OIL FILTER ADAPTER 9 ft-lbs
TRIM TORQUE REQUIREMENTS
M3-.5 PHILLIPS PAN HEAD SCREW INTO ALUMINUM 50 in-lbs
M6-1 TAPTITE SCREW INTO ALUMINUM 96 in-lbs
M6-1 TAPTITE SCREW INTO WELDNUT 96 in-lbs
M8-1.25 TAPTITE SCREW INTO ALUMINUM 18 ft-lbs
STARTER BRACKET TO BLOCK 18 ft-lbs
GOVERNOR LEVER PINCH BOLT 108 in-lbs
FLYWHEEL NUT 82 ft-lbs
SPARK PLUG 15 ft-lbs
RV TORQUE REQUIREMENTS
EXHAUST OUTLET BOLTS 18 ft-lbs
ROTOR BOLT 19 ft-lbs
ALTERNATOR ADAPTOR BOLTS 12 ft-lbs
STATOR BOLTS 12 ft-lbs
M6-1 TAPTITE SCREW INTO PIERCED HOLE 96 in-lbs
