5.00 Operation
To lift/lower and adjustment of chassis leg in/out
• To lift the patient press UP arrow and to lower
the patient press DOWN arrow on the hand
control or the control box.
• On GL5 mobile lifter the leg spread width
adjustment of the chassis is operated via the
sideways arrows on the hand control or the
control panel on the control box.
• Use maximum width setting when lifting to/
from wide chairs, or as necessary when lifting
to/ from bed, toilet and oor.
• The hand control is designed to be parked on
the retainer between the control box and the
lifting actuator, for easy access when handling
patient.
• When maneuvering the lifter the chassis legs
must be in the closed narrow position.
