M00000118- E-uk – 06.07 DL645 and Simplex 45
Power Rating: Depend on the mechanism configuration:
Fail-Safe in N/C mode: 39W Stand by or Alarm
30W Passage
Fail-Safe in N/O mode: 10W Standby or Passage
39W in Alarm condition
Fail-Lock in N/C mode: 10W Stand by or Alarm
20W Passage
If equipped of optional Drop Arm device:
Fail-Safe in N/C mode: 50W
Fail-Safe in N/O mode: 20W Standby or Passage
50W in Alarm condition
Fail-Lock in N/C mode: 20W
Logic Voltage: 24Vdc
Power Failure: In the event of an emergency or isolation of the power
supply the Hercules-Lite Tripod can be configured to
Fail-Safe i.e. rotates freely or Fail-Lock i.e. locks in the
HOME position.
Either option is available in both or one direction.
Fire Alarm: Input facility available for free voltage contact (normally
closed) supplied by others to effect fail state.
Interface: The mechanism is controlled by means of a
Microprocessor control logic with the following features:
• Three Built-In sensors detecting the mechanism
position
• One input for opening the mechanism in each
direction.
• Four protected outputs (refer to LEDs / Way mode
indicators in Section 4) for piloting light mode
indicators (2 symbols)
• Two protected outputs available for counting
passage in either direction.
• Two dry contacts (0V) output relays available for
indicating availability of use in either direction or
availability for counting passage in either direction.
• Two open collector NPN outputs (refer to EXIT
Characteristics in Section 4) available for indicating
use in either direction or availability for counting
passage in either direction or activate alarms
and/or the ‘Drop Arm’ features.
• One serial port – RS485
Operating Temperature: 0 to 45°C
Transportation and Storage: -25 to +55° C
Relative Humidity: 95% Non condensing.
