M00000118- E-uk – 06.07 DL645 and Simplex 45
Technical Details
The Hercules-Lite turnstile consists of stainless steel cabinet which dimensions and shape
depend on the model.
The cabinet contains and supports the mechanism that controls the rotation of a Head
Assembly that has three tubular arms. These arms are positioned at 120° intervals so that when
the unit is at rest one arm will always be in the horizontal position – BARRIER POSITION.
The movement of the head assembly is controlled by two solenoid devices, which allow rotation
in both directions.
The passageway can be controlled by devices such as card readers, or local and remote push
buttons.
The head assembly is moved manually by the person using the turnstile.
Technical Specification
Orientation: Pass Left or Pass Right
Drive: Hand Operated
Material: Stainless steel AISI 304 Scotch-Brite
TM
finished
Casework Lid Standard stainless steel AISI 304 Scotch-Brite
TM
finished
Hercules-Lite Tripod Hub: Cast Aluminium with grey finish.
Hercules-Lite Tripod Arms: 38mm diameter 480mm AISI 304 polished stainless
Steel with welded end caps.
Function: Passage in both directions, electronically controlled.
Mechanism: Control of the Hercules-Lite Tripod operation is
achieved by an electro- mechanical head mechanism
located within the top section of the turnstile casework.
The unit has the following features as standard:
Normally Closed
– The mechanism is locked until a
valid authorisation signal is received.
Normally Open
– The mechanism is permanently
unlocked and will only lock if passage is attempted
without a valid authorised signal.
In this mode the MTBF is increased from 1.5 to 2.5
million cycles and increases passage through-put
speed.
Power Supply: 115/230 Vac 50/60Hz
