17
M00000118- E-uk – 06.07 DL645 and Simplex 45
Alarms
If a person attempts to rotate the Hercules-Lite Tripod without authorisation having been
received from the reader unit the control logic will interpret this as an attempt at fraud (‘Fraud’
alarm). In the SA mode the solenoid locks rotation.
The rocker arm is released when the Hercules-Lite Tripod returns to the BARRIER position.
In every case, the tripod rotation must be completed within 8 seconds from the leaving of the
BARRIER position, otherwise the control logic will signal an alarm (‘Positioning’ alarm). The
alarm is reset when the Hercules-Lite Tripod returns to the BARRIER position.
If the Hercules-Lite is equipped of Drop Arm device, the control logic detects if the arm in barrier
position is dropped. In that case, the control logic will signal an alarm (‘Drop Arm’ alarm). The
alarm is reset when the arm is restored in the barrier position.
The Simplex 45 ATT model is equipped of two photocells and/or a sensitized top lid in order to
recognise the attempts of cross the barrier without authorization. If these sensors are activated
when the control logic is not processing any authorized rotation, an alarm will be triggered. That
alarm is reset 3 seconds after the sensors de-activation.
The photocells alarm is automatically inhibited when the Unlock operating mode is set for, at
least, one direction. In that case, only the sensitized top lid alarm is active.
During all the described alarm conditions, the control logic locks the rotating head and signals
that status by means of the buzzer activation, the flashing red cross on the traffic lights and
activating a dry contact output.
By means of a trimmer (see Section 8 – table 8.8). it is possible to choice which alarm has to be
signalled by the dry contact output.
Remote Control interface
The Hercules-Lite turnstile control logic offers an electrical interface in order to allow the remote
control of entrance.
By means of the optional Gunnebo Entrance Control MP2000 control module, the operation
modes of the unit can be set by a remote consol (see connection details is Section 5 of this
manual).
In case the remote control is needed, a trimmer of the LL2001 must be set as described in
Section 8 – table 8.7.
RS485 Serial Line
The Hercules-Lite turnstile control logic can be interfaced with RS485 serial line using the
Gunnebo Entrance Control proprietary protocol. In this way the operating modes, alarms and
transit information are available for full integration with the access control system.
In case the serial line connection is used, a trimmer of the LL2001 must be set as described in
Section 8 – table 8.7.
If more than one Hercules-Lite turnstile unit must be connected to the same bus, it is possible to
assign an address to each one by means of the dip-switches mounted on the LL2001 electronic
board. Up to 16 units can be addressed into the bus (see section 8 - table 8.9 for addresses
assignment).
The description of the proprietary protocol can be required to the Technical Support; connection
details are available in Section 5 of this manual.
In order to improve the interfacing capability of the serial line, it is possible to slow down the
transmission flow from the Hercules-Lite turnstile’s serial port by means of a trimmer mounted
on the LL2001 electronic board (see section 8 – table 8.3).
