18
M00000118- E-uk – 06.07 DL645 and Simplex 45
Programmable Parameters and Trimmers
The Hercules-Lite turnstile operational modes are affected by the positions of the eight trimmers
mounted on the LL2001 board; their functionality is resumed in Section 8 of this manual.
When the control logic microprocessor executes the resident program it consults the current
position of the trimmers in order to set the timings of certain actions and internal algorithms.
Note
When ONE or MORE trimmer position is changed, it will be necessary to press
the RESET Button on the LL2001 Board.
Modifications to the trimmers setting should only be carried out by trained
personnel.
When the trimmers setting is changed, it is important to record the new and the
old configuration.
Reader Authorization Signal Management
In the Reader-Controlled Mode, the logic system waits for the card reader to send an unlock
signal that authorizes passage.
The signal sent by the reader can be interpreted in three ways.
Unlock on Front: the logic identifies as authorisation the transition from non active to
active (of the unlock signal). In this moment the logic starts to count down the transit
time out;
Unlock on Level: the logic identifies as authorisation the transition from active to non
active (of the unlock signal). In this moment the logic starts to count down the transit
time out;
Copy: the logic keeps the system unlocked for a period corresponding to when the
reader signal is sent.
Operate the choice by means of a trimmer mounted on the LL2001 electronic board (see
section 8 – table 8.2).
The “Unlock on Front” mode is set by default from factory. In this modality, the logic records
authorisation signals that arrive while the door is still being used.
The maximum number of authorisation signals that can be recorded is determined by the TR4
trimmer position.
See also section 5 for connection details.
