GUSMER H-2000 - Page 9

Operating Manual Description
4/1/99
9
1. MAIN CIRCUIT BREAKER
Controls and protects power to all circuits; must be ON for any function of the
proportioning unit to operate.
Pilot light (White)
Indicates when lighted that the main circuit breaker is on.
2. MOTOR CONTROL
Controls power to the electric motor; must be ON for the hydraulic drive system to
operate.
Pilot light (Amber)
Indicates when lighted that the electric motor is on.
3. PUMP SWITCH
controls operation of the hydraulic drive system;
OFF
Hydraulic Directional Drive System is off, and cannot generate hydraulic pressure
in this position.
NORMAL
Must be in this position for the proportioning pumps to operate.
RETRACT
This position should be used for shutdown and will stop the Hydraulic Drive
System with the A proportioning pump in the retracted position.
4. PUMP DIRECTIONAL
INDICATOR LIGHTS (Amber)
Indicates the direction of proportioning pump travel; both lights will be off when
the pump switch is OFF or when either proportioning pump exceeds its safe
operating pressure limitation.
5. COUNTER
Records the cycle count of the proportioning pumps; one cycle equals two (2)
strokes (one in each direction).
6. R-PRIMARY HEATER CIRCUIT
BREAKER
Controls and protects power to the R primary heater; must be ON for the primary
heater to operate.
Pilot light (Amber)
Indicates when lighted that the R Primary Heater Circuit Breaker is on.
7. A-PRIMARY HEATER CIRCUIT
BREAKER
Controls and protects power to the A Primary Heater; must be ON for the Primary
Heater to operate.
Pilot light (Amber)
Indicates when lighted that the A Primary Heater Circuit Breaker is on.
8. PUSH TO TEST BUTTON
Push button daily to test Primary Heater Circuit Breakers. Circuit Breaker must
trip when this button is pushed.
9. R-PRIMARY HEATER
CONTROLLER
Controls the temperature of the liquid maintained by the R primary heater; set
control selector (dual scale, Fahrenheit or Centigrade) to the desired
temperature. From this point, the temperature control is completely automatic.
Green Controller Light
Indicates when lighted that the temperature of the Resin component in the heater
is within +/- 5° F of dial set point.
Amber Controller Light
Indicates when lighted that the temperature of the Resin component in the heater
is more than +/- 5° F cooler than dial set point.
Red Controller Light
Indicates when lighted that the temperature of the Resin component in the heater
is more than +/- 5°F warmer than dial set point.
10. A-PRIMARY HEATER
CONTROLLER
Controls the temperature of the liquid maintained by the A Primary Heater. Set
Control Selector (dual scale, Fahrenheit or Centigrade) to the desired
temperature. From this point, the temperature control is completely automatic.
