GVision MA15BX - 12 Display Modes

20 of 41
12. Display Modes
Display
Size
Resolution Type H. Scan V. Scan Pol. Pixel
(KHz) (Hz) (MHz)
640X350 VGA 31.469 70.087 + / - 25.175
640X400 VGA 31.469 70.087 - /+ 25.175
720X400 VGA 31.469 70.087 - / + 28.322
640X480 VGA 31.469 59.940 - / - 25.175
640X480 VESA72 37.861 72.809 - / - 31.500
640X480 VESA75 37.500 75.000 - / - 31.500
800X600 SVGA 37.879 60.317 + / + 40.000
800X600 VESA72 48.077 72.188 + / + 50.000
800X600 VESA75 46.875 75.000 + / + 49.500
1022 X 512 34.39 60.000 + / + 46.77
1024X768 VESA60 48.363 60.004 - / - 65.000
1024X768 VESA70 56.476 70.069 - / - 75.000
15” 17” 19”
1024X768 VESA75 60.023 75.029 + / + 78.750
1152X864 VESA 67.5 75.5 + / + 108.0
1280X1024 VESA 64.3 60.0 + / + 108.0
17” 19”
1280X1024 VESA 80.0 75.0 + / + 135.0
