FUNCTION GENERATOR-SERIES
INSTRUCTION MANUAL
9
GFG-
8215A/8216A/8217A/8219A
GFG-
8250A/8255A
11.Frequency Modulation (for GFG-8219A/8255A only)
Deviation
0～±5％ 0～±5％
MOD.Freq.
400Hz(INT),DC～20kHz(EXT) 400Hz(INT),DC～20kHz(EXT)
EXT Sensitivity
≦10Vpp for 10％ modulation ≦10Vpp for 10％ modulation
12.Frequency Counter
Int./Ext. Switch selector Switch selector
Range
0.3Hz～3MHz
(5Hz～150MHz EXT)
0.5Hz～5MHz
(5Hz～150MHz EXT)
Accuracy
Time base accuracy±1count Time base accuracy±1count
Time base
±20ppm(23℃±5℃) after
30 minutes warm up
±20ppm(23℃±5℃) after
30 minutes warm up
Resolution
The maximum resolution is
10nHz
for 1Hz and
0.1Hz for 100MHz.
The maximum resolution is
10nHz for 1Hz and
0.1Hz for 100MHz.
Input Impedance
1MΩ/150pF 1MΩ/150pf
Sensitivity
≦35mVrms(5Hz~100MHz)
≦45mVrms(100MHz~150MHz)
*GFG-8215A does not have
Frequency Counter function.
≦35mVrms(5Hz~100MHz)
≦45mVrms(100MHz~150MHz)
13.General
Power Source
AC115V, 230V±15%,50/60Hz AC115V, 230V±15％,50/60Hz
Operation
Environment
Indoor use, altitude up to 2000m.
Ambient Temperature 0℃ to 40℃.
Relative Humidity 80%(Maximum).
Installation category II
Pollution Degree 2
Storage temperature
& Humidity
-10℃ to 70℃.
70% (Maximum).
FUNCTION GENERATOR-SERIES
INSTRUCTION MANUAL
10
GFG-
8215A/8216A/8217A/8219A
GFG-
8250A/8255A
Accessories
GTL-101×2
*GTL-101×1 for GFG-8215A
Instruction manual×1
GTL-101×2
Instruction manual×1
Dimension
251(W)×91(H)×291(D) m/m 251(W)×91(H)×291(D) m/m
Weigh
Approx. 2.0kgs-GFG-8215A
2.1kgs-GFG-8216A
2.15kgs-GFG-8217A
2.2kgs-GFG-8219A
Approx. 2.3kgs-GFG-8250A
2.4kgs-GFG-8255A
Measurement category I is for measurements performed on circuits not
directly connected to MAINS.
Measurement category II is for measurements performed on circuits directly
connected to the low voltage installation.
Measurement category III is for measurements performed in the building
installation.
Measurement category IV is for measurements performed at the source of
the low-voltage installation
.
WA RN IN G ： To avoid electrical shock, the power cord
protective grounding conductor must be connected to ground.
CAUTION：To avoid damaging the instrument, do not use it
In a place where ambient temperature exceeds 40℃.
CAUTION：To avoid damaging the instrument, do not input
more than DC15V to V.C.F.(V.C.G.).
CAUTION：To avoid damaging the instrument, do not input
more than AC150V to Frequency Counter (for GFG-8216A,
GFG-8217A, GFG-8219A, GFG-8250A, and GFG-8255A).
CAUTION：To avoid damaging the instrument, do not input
more than AC10Vpp when proceed EXT modulation
operation (for GFG-8219A, GFG-8255A).
