FUNCTION GENERATOR-SERIES
INSTRUCTION MANUAL
5
2. INTRODUCTION
The Function Generator series are stable low distortion instruments
which generate signals in the frequency range up to 5MHz. Typical
applications include a wide range of audio response testing applications,
vibration testing, servo system evaluation, ultra sound applications, and etc.
These instruments include the following features: logarithmic and linear
sweep capabilities, together with a built in frequency counter. The sweep
capability simplifies the task of finding resonant points of speakers, filter
networks and other networks/structures. An oscilloscope may be connected
to this instrument for the response to be displayed. The counter can be
switched to measure and display the frequency of an external signal up to
150MHz.
z ADDITIONAL FEATURES
1.Low distortion waveforms (sine, triangular and square) and ramp signal.
2.Signal output in seven decade stages, 0.5Hz to 5MHz for GFG-8250A/8255A,
0.3Hz to 3MHz for GFG-8215A/8216A/8217A/8219A.
3.Adjustable sweep time and sweep width both in linear and logarithmic
modes.
4.Duty cycle control with signal inversion capability.
5.External Voltage controlled Frequency (VCF).
6.AM or FM modulation modes with internal or external modulation control.
FUNCTION GENERATOR-SERIES
INSTRUCTION MANUAL
6
7.A second output for TTL or adjustable CMOS pulses.
8.50 ohm main signal output with DC offset adjustment and 20dB attenuation
capability.
9. Supplied with two BNC test leads and AC power cord set.
z FEATURES COMPARISON TABLE FOR MODELS:
MODEL
FEATURE
GFG-
8215A
GFG-
8216A
GFG-
8217A
GFG-
8219A
GFG-
8250A
GFG-
8255A
AM/FM
───ˇ─ˇ
SWEEP
──ˇˇ─ˇ
COUNTER
─ˇˇˇˇˇ
GCV Output
───ˇ─ˇ
TTL/CMOS
ˇˇˇˇˇˇ
VCF
ˇˇˇˇˇˇ
Duty Cycle
Control
ˇˇˇˇˇˇ
