光毓机电 RMD-X8
V1.0
Motor/Encoder Direction：The direction of motor and encoder calibration, which is a
read-only parameter, generally has no effect on motor drive performance.
Motor/Encoder Align Power：Motor and encoder calibration power, generally use the
default parameters.When the load is large, it can be increased appropriately to
improve the calibration effect.
Align button：Start motor and encoder calibration. Before this step, it is necessary to
ensure that the number of magnetic poles of the motor is set correctly and that the
appropriate calibrated power is selected. After clicking the Align button, the motor
will rotate back and forth to perform the calibration, and the parameters will be
automatically saved to the driver after the calibration completed.
Motor Zero Position：Motor starting position. After clicking the Set button, the
driver will save the current position as the motor starting position.
Note:
1.The calibration of the motor and encoder should be carried out at the condition of no
load of the motor. If the motor does not rotate smoothly during the process of calibration,
please check whether there is any fault of the motor or excessive mechanical friction.
2. After the parameters modified, click the Write button to save the parameters to the
driver.
4.4 Product Information
In the Product page, click the Read button to get the driver model, motor type, hardware
and software versions of the driver.
