H3C Mini Series User Manual

13
Item S8G-U S9-PWR S16G-U
PoE power
supply
Not
supported
Supported by
ports 1
through 8.
A maximum
PoE power
capacity of 30
W per port
Not supported
Power
consumption
(static)
0.5 W 2 W 7.8 W
Power
consumption
(full
configuration)
≤ 4 W ≤ 70 W ≤ 11 W
Cooling
system
Natural cooling
Input voltage
DC: 12 V/0.5
A
DC: 54 V/1.48
A
AC: 100 VAC
to 240 VAC @
50 Hz or 60 Hz
Port
specifications
RJ-45 connector
Half/full duplex, auto-negotiation, MDI/MDI-X
Overall
leakage
current
GB4943.1
Operating
temperature
0°C to 40°C (32°F to 104°F)
Operating
relative
humidity
5% RH to 95% RH, noncondensing

H3C Mini Series Specifications

General

Brand	H3C
Model	Mini Series
Category	Switch
Language	English
