H3C Mini Series User Manual

14
Item S8G-U S9-PWR S16G-U
Fire
resistance
compliance
GB4943.1
Table 3 Technical specifications (2)
Item S24-U S24G-U
Dimensions (H
× W × D)
44 × 330 × 173 mm
(1.73 × 12.99 × 6.81
in)
44 × 330 × 173 mm
(1.73 × 12.99 × 6.81
in)
Weight ≤ 1.5 kg (3.31 lb) ≤ 1.6 kg (3.53 lb)
Port
24 × 10/100Base-TX
copper port
24 ×
10/100/1000Base-T
copper port
PoE power
supply
Not supported Not supported
Power
consumption
(static)
3.7 W 7.8 W
Power
consumption
(full
configuration)
≤ 9 W ≤ 16.5 W
Cooling system Natural cooling
Input voltage AC: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
Port
specifications
RJ-45 connector
Half/full duplex, auto-negotiation, MDI/MDI-X
