Figure 91 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5024PV3-EI-PWR
Figure 92 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Mode button
(3) 10/100/1000BASE-T autosensing Ethernet port LED
(4) SFP port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) Console port (CONSOLE)
(8) SFP port
Figure 93 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1 2
1
7
3
8 6
2 4 5
1
2
