H3C S5120V2-SI

60
Figure 97 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
S5024FV3-EI
Figure 98 Front panel
(1) SFP port
(2) 10/100/1000BASE-T autosensing Ethernet port
(3) SFP port LED
(4) System status LED (SYS)
(5) 10/100/1000BASE-T autosensing Ethernet port LED
(6) Console port (CONSOLE)
Figure 99 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
