4 Ports and LEDs
Ports
Console port
Table4-1 Console port specifications
Item Specification
Connector type RJ-45
Compliant standard EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal
• Provides connection to the serial port of a local PC running terminal
emulation program
Compatible devices All device models
Management Ethernet port
Table4-2 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Port transmission rate
• 10 Mbps, half/full duplex
• 100 Mbps, half/full duplex
• 1000 Mbps, full duplex
• MDI/MDI-X autosensing
Transmission medium Category-5 or above twisted pair cable
Max transmission distance 100 m (328.08 ft)
Compliant standard IEEE 802.3i, IEEE 802.3u, and IEEE 802.3ab
Functions and services Switch software and Boot ROM upgrade, network management
Compatible devices S5570S-54F-EI switch
2.5G/1000/100BASE-T Ethernet port
Table4-3 2.5G/1000/100BASE-T Ethernet port specifications
Item Specification
Connector type
RJ-45
Rate, duplex mode, and
auto-MDI/MDI-X
• 100 Mbps, half/full duplex
• 1 Gbps, full duplex
