H3C S5170-EI Series Hardware Information

Item S5170-28S-HPWR-EI S5170-54S-PWR-EI
Console port 1 × serial console port
SFP+ port 4 6
10/100/1000
BASE-T
autosensing
Ethernet port
24 48
Input voltage
AC input:
• Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
• Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
PoE power
capacity
• Total PoE power capacity: 370 W
• Max PoE power capacity per port: 30 W
Minimum
power
consumption
24 W 30 W
Maximum
power
consumption
(including
PoE power
consumption)
460 W 470 W
Power
efficiency
80 plus gold certified 80 plus gold certified
Chassis
leakage
current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Melting
current of
power supply
fuse
10 A/250 V
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating
humidity
5% RH to 95% RH, noncondensing
Fire
resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
S5570S-EI switch series
Table1-5 Technical specifications for non-PoE switch models
Item S5570S-28S-EI S5570S-54S-EI S5570S-36F-EI S5570S-54F-EI
Dimensions
(H × W × D)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
Weight ≤ 5.6 kg (12.35 lb) ≤ 6.0 kg (13.23 lb) ≤ 4.5 kg (9.92 lb) ≤ 4.5 kg (9.92 lb)
Console port 1 × serial console port
