H3C S5170-EI Series Hardware Information

Item S5170-28S-EI S5170-54S-EI S5170-36F-EI
Fire
resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Table1-3 Technical specifications for non-PoE switch models (2)
Item S5170-54S-EI-DP S5170-36F-EI-DP
Dimensions
(H × W × D)
43.6 × 440 × 320 mm (1.72 × 17.32 × 12.60
in)
43.6 × 440 × 260 mm (1.72 × 17.32 × 10.24
in)
Weight ≤ 4.3 kg (9.48 lb) ≤ 3.6 kg (7.94 lb)
Console port 1 × serial console port
SFP port N/A 24
SFP+ port 6 4
10/100/1000
BASE-T
autosensing
Ethernet port
48 8
Input voltage
AC input:
• Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
• Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
Minimum
power
consumption
• Single AC input: 23.5 W
• Dual AC inputs: 24 W
• Single AC input: 24.5 W
• Dual AC inputs: 25 W
Maximum
power
consumption
• Single AC input: 61.5 W
• Dual AC inputs: 62 W
• Single AC input: 60.5 W
• Dual AC inputs: 61 W
Chassis
leakage
current
compliance
UL62368-1/EN62368-1/IEC62368-1/UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Melting
current of
power supply
fuse
3.15 A/250 V
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating
humidity
5% RH to 95% RH, noncondensing
Fire
resistance
compliance
UL62368-1/EN62368-1/IEC62368-1/UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Table1-4 Technical specifications for PoE switch models
Item S5170-28S-HPWR-EI S5170-54S-PWR-EI
Dimensions
(H × W × D)
43.6 × 440 × 320 mm (1.72 × 17.32 × 12.60
in)
43.6 × 440 × 320 mm (1.72 × 17.32 × 12.60
in)
Weight ≤ 5.0 kg (11.02 lb) ≤ 5.5 kg (12.13 lb)
