H3C S5170-EI Series Hardware Information

Item S5570S-28S-EI S5570S-54S-EI S5570S-36F-EI S5570S-54F-EI
compliance
Table1-6 Technical specifications for PoE switch models
Item S5570S-28S-HPWR-EI S5570S-54S-PWR-EI S5570S-30MS-UPWR-EI
Dimensions
(H × W × D)
43.6 × 440 × 460 mm (1.72 ×
17.32 × 18.11 in)
43.6 × 440 × 460 mm (1.72 ×
17.32 × 18.11 in)
43.6 × 440 × 460 mm (1.72 ×
17.32 × 18.11 in)
Weight ≤ 5.5 kg (12.13 lb) ≤ 6.0 kg (13.23 lb) ≤ 8.5 kg (18.74 lb)
Console port 1 × serial console port
SFP+ port 4 6 6
2.5G/1000/1
00BASE-T-P
oE++
autosensing
Ethernet port
N/A N/A 24
10/100/1000
BASE-T
autosensing
Ethernet port
24 48 N/A
Power supply
slot
2, on the rear panel
Input voltage
• PSR180-56A power module (S5570S-28S-HPWR-EI and S5570S-54S-PWR-EI):
 Rated voltage range for AC input: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
 Rated voltage for DC input: 240 VDC
 Max voltage range for AC input: 85 VAC to 290 VAC @ 47 Hz to 63 Hz
 Max voltage range for DC input: 180 VDC to 320 VDC
• PSR360-56A/PSR720-56A power module:
 Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
 Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• PSR1110-56A power module:
 Rated voltage range: 115 VAC to 240 VAC @ 50 Hz or 60 Hz
 Max voltage range: 102.5 VAC to 264 VAC @ 47 Hz to 63 Hz
• PSR560-56D power module:
 Rated voltage range: –48 VDC to –60 VDC
 Max voltage range: –36 VDC to –72 VDC
 DC power source for the PSR560-56D power module: –48 VDC power source in
the equipment room or an RPS (H3C RPS1600-A)
PoE power
capacity
Depends on the power supply configurations. For more information, see Table1-7.
Minimum
power
consumption
• Single AC input: 42 W
• Dual AC inputs: 50 W
• Single DC input: 39 W
• Dual DC inputs: 55 W
• Single AC input: 47 W
• Dual AC inputs: 62 W
• Single DC input: 46 W
• Dual DC inputs: 64 W
• Single AC input: 47 W
• Dual AC inputs: 56 W
• Single DC input: 45 W
• Dual DC inputs: 64 W
Maximum
power
consumption
(including
PoE power
consumption)
• Single AC input: 870 W
• Dual AC inputs: 867 W
• Single DC input: 630 W
• Dual DC inputs: 873 W
• Single AC input: 1290
W
• Dual AC inputs: 1700
W
• Single DC input: 650 W
• Dual DC inputs: 1342
W
• Single AC input: 1270
W
• Dual AC inputs: 2430
W
• Single DC input: 670 W
• Dual DC inputs: 1350
W
