2
Figure1-1 Removing the access panel
6. Remove the chassis air baffle. As shown in Figure1-2, open the hooks marked by blue
trapezoids on the chassis air baffle, and then lift the air baffle up to remove it from the chassis.
Figure1-2 Removing the chassis air baffle
Installing the processor
The server can use one or two processors.
To prevent damage to the pins on the processor socket, always install a cover over an empty
processor socket.
• Make sure all processors on a server are the same model.
