H3C WA2600 Enhanced Series Installation Guide

7
LED
Color
QTY
Meaning
5GHz
(Wireless
link LED)
Green
1
Displays the 5 GHz wireless link
status:
 On: The wireless link is normal.
 Off: The wireless link is not
initialized or the link is faulty.
 Blinking slowly: The wireless link
works normally.
 Blinking rapidly: Data is being
transmitted or received.
10/100M
(Ethernet
interface
LED)
Yellow
1
Displays the status of the Ethernet
interface:
 On: The Ethernet interface is in the
link-up state.
 Off: The Ethernet interface is in the
link-down state.
 Blinking: Data is being transmitted
or received at 10/100 Mbps.
1000M
(Ethernet
interface
LED)
Green
1
Displays the status of the 1000 M
Ethernet interface:
 On: The Ethernet interface is in the
link-up state.
 Off: The Ethernet interface is in the
link-down state.
 Blinking: Data is being transmitted
or received at 1000 Mbps.
Interfaces
The WA2600 enhanced series provides a reset button, security slot, and the following
interfaces:
 2.4 GHz or 5 GHz antenna interfaces
 A console interface
 An Ethernet copper interface
 A power supply interface
To view interface details, see Figure 5 Figure 6 and Table 4

H3C WA2600 Enhanced Series Specifications

General

Brand	H3C
Model	WA2600 Enhanced Series
Category	Wireless Access Point
Language	English
