Table 3-4 Port descriptions
RESET N/A For more information, see Table 3-3.
Console port RS/EIA-232
Used by technical personnel only for
device configuration and management.
GE/PoE
• IEEE802.3
• IEEE802.3i
• IEEE802.3u
• IEEE802.3ab
• IEEE802.3af
10/100/1000M Ethernet copper port, used
for connecting the AP to an uplink device
for Internet or MAN access. It can also
receive PoE power from the uplink device.
When the AP operates in fit mode, the port
is represented by interface number
GE1/0/1 in the MAP file and
gigabitethernet 1 for configuration on the
AC.
2.5GE/SFP IEEE802.3 1000/2500M Ethernet fiber port.
54V DC N/A
Power port, used for receiving +54 VDC
power from a local power source.
