1-1
1 Appendix C Optional transceiver
modules
Views
You must use an SFP transceiver module and optical fiber with an LC connector to connect the fiber
port on the AP.
Figure1-1 SFP transceiver module
Figure1-2 Optical fibers with LC connectors
Specifications
Table1-1 SFP-2.5G-LX10-SM1310-DR-I transceiver module specifications
Item SFP-2.5G-LX10-SM1310-DR-I
Central wavelength 1310 nm
Max transmission distance 10 km (6.21 miles)
Data rate 1228.8 to 2457.6 Mbps
Connector type LC connector
Fiber mode SMF
Fiber diameter 9/125 μm
Output power –7 to +2 dBm
