Haaga 697 - Page 11

haaga 677 / 697 / 697 plus
42
EN
17
16
15
14
Fig. 2: Component overview 2
Item no. Component
14 Fine sweeping roll
15 Helical gear
16 Sweeper lip
17 Sweeping plate
18
19
Fig. 3: Component overview 3
Item no. Component
18 Dust lter
19 Type plate
Construction and Function
22
20
21
23
Fig. 4: Component overview 4
Item no. Component
20 Clutch housing
21 Toothed sleeve
22 Helical gear toothing
23 Drive protection
26
25
24
Fig. 5: Component overview 5
Item no. Component
24 Battery
25 Battery connection lead (red
+
)
26 Battery connection lead (blue -)
