ES0205l 12-00
5
SPECIFICATIONS
Table
Travels: X - 16 inches, Table: Work Surface Length - 28.75 inches,
Y - 12 inches, Total Length - 36 inches,
Z - 10 inches. Width - 12 inches.
The Mini Mill has 10" of workspace Z-axis travel and features an additional 3.75 of Z travel to facilitate tool
changing. This extra travel is available for use for fixture clearance or light duty machining. The linear guide
rails are not fully supported at this elevated head position and thus heavy cut performance cannot be
guaranteed.
T-Slots: Width - 0.625 inches, Spindle Nose To Table: 4 inches to 14 inches.
Center Distance - 4.33 inches, Overtravel: Up to 17.75 under spindle.
Quantity: 3 T-Slots.
T-Slots, optional
Metric Table: Width - DIN 650-14
Center Distance - 110 mm
Quantity: 3 T-Slots.
Spindle
Spindle: Taper Size - #40 Taper,
Speed - 6000 RPM,
Transmission - Direct-Speed Belt Drive.
Spindle Motor Rating: 3ph Power - 7.5HP peak, 5HP continuous,
1ph Power - 7.5HP peak, 5HP continuous.
General
Feed Rates: Maximum Cutting Feed Rate - 500 ipm. Rapid on Z-Axis - 650 ipm.
Rapid on X-Axis - 650 ipm,
Rapid on Y-Axis - 650 ipm,
Tool Changer: Capacity - 10 tools,
Type - CT-40 or BT-40,
3.5 Maximum Tool Diameter,
12.0 lbs. Maximum Tool Weight
4.0 second Tool to Tool Change Time
5.4 second Chip to Chip Change Time
Air Required: 4 scfm, 100 psi, 3/8 hose.
Coolant Capacity: 24 gallons (optional).
Power Required: 3ph Power - 208V @ 25A 9KVA,
1ph Power - 240V @ 40A 9KVA.
Weight: 3400 lbs.
