ES0205l 12-00
7
SHIPPING BRACKET
NOTE: Remove and discard the shipping bracket, located on the top right of the Mini
Mill door.
Door
Shipping Bracket
SHCS (4)
Mini
Mini
Mill
Mill

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haas Mini Mill and is the answer not in the manual?

Haas Mini Mill Specifications

General IconGeneral
Spindle Speed6, 000 rpm
X Axis Travel406 mm (16 in)
Y Axis Travel305 mm (12 in)
Z Axis Travel254 mm (10 in)
Spindle Power5.6 kW (7.5 hp)
Tool Capacity10 tools
Table Size914 mm x 305 mm (36 in x 12 in)
Spindle TaperCT40
Rapid Traverse X Axis15.2 m/min (600 in/min)
Rapid Traverse Y Axis15.2 m/min (600 in/min)
Rapid Traverse Z Axis15.2 m/min (600 in/min)
